| Prod Model: |
P4-I |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: |
(W)256mmx(H)128mm |
| Resolution: |
64X32 Dots |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Pitch: |
4mm |
| Scanning Mode: |
1/16 Scan |
| System Operating Platform: |
WIN XP |
| Display Type: |
LED Video Display |
| Application: |
Shopping Guide |
| IP Rating: |
IP43 |
| Certification: |
FCC |
| Pixel Configuration: |
3in1 SMD |
| Pixel Density: |
62500 |
Product Description
Product Details
Basic Info.
Model NO.:P4
Tube Chip Color:Full Color
Display Function:Video Display
Pixel Pitch:4mm
Pixel Configuration:3in1
Pixel Density:62500 dots / m²
Scanning Mode:1/16 Scan
System Operating Platform:WIN XP
Display Type:LED Video Display
Application:Stage Performance, Advertising, Shopping Guide, Stage Performance
IP Rating:IP43
Certification:CE, RoHS, FCC, CCC, ISO9001
Pitch:10mm
Module Size:(W)256mmx(H)128mm
Resolution:64X32 Dots
Density:62500dots/Sqm
LED Chip:Epistar
Pixel Color:3in1
LED Spec:SMD3in1
Brightness:More Than 2200CDS/Sqm
Scanning Method:1/16
Best View Distance:6-20m
Export Markets:Global
Additional Info.
Trademark:J-Cai
Packing:Carton
Standard:CE, ROHS, FCC.
Origin:Quanzhou
HS Code:8531200000
Production Capacity:40, 000.00PCS Safety Stock Every Month
Product Description
BRILLIANTOPTO CO.,LIMITED
P10 indoor SMD full color LED display:
1. Manufacturer: over 10 years
2. Brightness: ≥2200cd/m2
3. Average power consumption: ≤485 W/m2
4. Quick response: replying inquiry within 12hrs
5. On time delivery + patient after-sales service
6. Quality guarantee: CE, RoHS, FCC, IP65, ISO9001 + 100% testing before shipping.
Company Brief Introduction:
Brilliant Optoelectronic Co., Ltd was founded in 2005, the top 3 in Fujian, China, with registered capital 20.18 million RMB and 40,000 m2 workshop. Quanzhou New Branched Factory founded in 2013, total area 20,000.00 m2, which highly improved our production capability.
Our company specialized in the development and manufacturing of LED display systems. Main products: modules, indoor & outdoor LED display and semi-outdoor LED display. Our company has been awarded CE, RoHS, FCC, IP65, ISO9001 certifications etc,.
A team with 15 professional experts and 400 trained technicians, our technology strength is among the front row in this industry. Strict quality control, quick delivery and good after-service enable us to win trust from the worldwide market.
Through our efforts, our products earned high reputation in Europe, North/South America, Australia, the Middle East and Southeast Asia. Welcome to contact Brilliantopto today!
Products related:
LED Display /LED display screen/LED sign/LED video wall
1. Modules: P1.9, P2.5, P3, P4, P5, P6, P7.62, P8, P10, P12, P12.5, P13.33, P16, P20, P25 etc
2. Display Color: 256*256*256
3. LED Chips: Opto, Epistar, Silan, Huacan, Sanan
4. Raw Materials: Toshiba IC, MBI IC, Chuanglian Power Supply, Meanwel Power Supply, Meanwel fans, ADDA fan, Beijing glue, Korean glue.
5. Cabinet: Standard cabinet, simple cabinet, customized cabinet, cabinet for rental, Iron or Aluminum cabinet, cabinet for front maintenance, cabinet with lock, special cabinet with Southco Lock, for hung and rental and etc.
6. Package: Flight case, wooden box package & carton box and etc.
7. Guarantee: 1 year
Application Case:
Widely used for shopping malls, entertainment venues, schools, government agencies, trade fair, fair, aiming at the exhibition, press conference, meeting rooms, cinemas, airports, hotels, internal, station waiting area, indoorstadium, and a variety of public facilities and etc.
Our service:
1. Inquiry response time: within 12hrs.
2. OEM&ODM: design and produce your customized requirements.
3. Provide distributorscustomized design andmodels we already have.
4. Protectyour sales area, design idea and all your private information.
5. Top quality+reasonable price+ patientafter-sales service.
6. Brilliant Opto can also offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and LED large screen full color display.
Trade Terms:
1. Package: anti-shaking wooden package, air flight case or carton package.
2. Payment: T/T, 30% deposit before production, 70% balance to be paid before delivery.
3. Free to support and train your operator.
4. Shipping port: XIAMEN, Mainland China.
5. Warranty time: 1 year
6. Delivery time: 3-14 working days.
Pixel pitch(mm) | 4mm |
| Size(W×H) | 256mm×128mm |
| Density(dots/ m2) | 62500dots/sqm |
| Resolution(W×H) | 64*32dots |
| Lamp orgin | Epistar |
| Colors | 1R1G1B |
| Led pecs | SMD3in1 |
| Module resolution | W64×H32 dots |
| Best viewing distance | 5-20m |
| Best view angle | H160,V110 |
| Environment temperature | -40°C ~ +85°C |
| Working temperature | -20°C ~ +50°C |
| RH | ≤10~90% |
| Module Weight | About 180g |
| Working voltage | 220V±10% |
| Suitable voltage | DC5V |
| Average Power consumption | 220W/m2 |
| Largest power consumption | 500W/m2 |
| Computer | More than p4-80G/512m |
| Control system | WIN 2000/ NT/XP/7 |
| Control method | LINSN synchronous control system |
| Spending card | kilomega network card |
| Scanning method | 16s constant current |
| Frame frequency | ≥60HZ |
| Refresh frequency | ≥300HZ |
| Gray color | 4096 lever, can display 16.7M colors |
| Brightness | ≥2200cd/m2 |
| Brightness control lever | software can chance 100 lever |
| Video signal | PAL/NTSC |
| Input/Output | 8 input/8output |
| MTBF | ≥10000H |
| life | 100000H |
| Power | 5V/40A |
Workshop:
Packing:
Project case:
Brilliantopto Co., Limited Was founded in 2005, with a registered capital of 20.18 million Yuan, a workshop covering an area of 20000 square meters and independent living and production places. Our company is professional in the development and manufacture of LED display systems. Our company technology strength is among the front row in this area, with a vigorous team.
In March, 2011, our company independently researched and developed a full-color formal P16 LED display, which can completely replace the current market single color LED displays, being the perfect choice in the next line of LED display market. In June, 2011, after designing P10 optical modules, we ceremoniously rolled out P10 light module series, which can effectively enhance the efficacy by above 10% and can effectively avoid a screen phenomenon. In August, 2011, our company took the lead in Quanzhou LED industry technology innovation strategy alliance. As the President unit, our company set up "Quanzhou LED Technology Research Center", featuring the national quality supervision center. Our company has many experts and professors from Xiamen University Semiconductor Research Center, Fuzhou University and Beijing University Institute of Photoelectricity for our research center technology consultation to comprehensively promote Quanzhou LED industry. In November, 2011, relying on our strong technical research and development team, we made a new generation of international leading 3D display screens.
Through six years of unremitting efforts, our company has successively obtained such honorary titles as The State Ministry Of Small-Sized And Medium-Sized Enterprise Technology Innovation Fund Project Unit, Small-Sized And Medium-Sized Enterprise In Fujian Province Technology Innovation Fund Project Unit, ISO9001 International Quality Management System Authentication Enterprise, CCC China National Mandatory Product Certification Enterprise, CE Compulsory Product Certification Enterprise, FCC Anti-Radiation Product Authentication Enterprise, RoHS Lead-Free Environmental Protection Product Authentication Enterprise, IP65 Waterproof and Dustproof Product Authentication Enterprise, Chinese Optical Optoelectronic Industry Member Unit, National Taxpayer Service Work Outstanding Member Unit, Unit With 15 Independent Research And Development Patents Of The State Intellectual Property Office, Fujian Quality And Right Protection Service (Member) Unit, Fujian Integrity And Labor Advocate Unit, Quanzhou Industry And Commerce Credit Good Enterprise, Quanzhou Creditable Unit, Quanzhou LED Technology Research Center and Quanzhou LED Industry Technology Innovation Strategy Alliance Chairman Unit.
Our company always implements our development target and insists on the tenet of "customers are the growing power source". Our company has a perfect after-sales service system, truly realizing that customers are the centers of the market marketing model.
Through our efforts, our products have been sold well in Europe, North America, Australia, the Middle East and Southeast Asia. Our company has set up stable sales agents in the corresponding areas. Our company sincerely hope to cooperate with LED display system talents and dealers for common development and for the development of LED display systems.
