| Prod Model: |
P4 Indoor Die Cast LED Display |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: |
288*288 |
| Cabinet Material: |
Iron or Aluminum |
| Brightness: |
More Than 2000 CD / Sqm |
| Cabinet Size: |
576*576 |
| Warranty: |
Two Years |
| Display Type: |
LED Video Display |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Scanning Mode: |
1/16 Scan |
| Certification: |
CCC |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Pitch: |
4mm |
| Application: |
Shopping Guide |
| IP Rating: |
IP43 |
| System Operating Platform: |
WIN XP |
| Pixel Density: |
62500 DOT / M² |
Product Description
Indoor Die Cast LED Display Series:
Application:Stage Performance, Advertising, Shopping Guide, Port, Station, Rental, Stadium, Dynamic Informatio
Export Markets: Western Europe,South America,North America,Mid East,Southeast Asia,Eastern Asia,Africa,Oceania etc.
| Parameters | Indoor Die-casting LED display classical series(576*576) |
| Pixel Pitch (mm) | 4 mm | 5.33mm | 6mm |
| Pixel density(pix/m2) |
43402 | 35200 | 27777 |
| LED Type | SMD3528 |
| Viewing Angle | H:140°,V:140° |
| Brightness(nits) | 2500 | 2500 | 2000 |
| Drive Method | 1/15 | 1/9 | 1/12 |
| Color Depth | 16bit |
| Refresh Rate(Hz) | 600HZ | 1200HZ |
| Module Size (mm) | 288×288 |
| Cabinet Size(mm) | 576×576 |
| Cabinet Material | Die-cast aluminum |
| Cabinet weight(kg) | 10.5 |
| Voltage | 110/250V |
| Average.power(W / m2) | 170 | 270 | 190 |
| Max.power (W / m2) | 500 | 800 | 560 |
| IP Grade | IP31 |
| Operating temperature/humidity | temperature:-20ºC~ 50ºC humidity:10~90%RH |
| Storage temperature/ humidity | temperature:-40ºC~ 60ºC humidity:10~90%RH |
| Lifetime(h) | ≥50000 |
| Compliant Standard | CCC,CE,Rosh |
P4 Full Color Rental Indoor LED Display Specifications:
Stable, Durable, easy to use
eat appearance , compact structure, stable performance, interest in color performance
P4 LED display screen is special made for application of giant indoor advertising screen. Use synchronous system which can accept signals DVI, VGA, HDMI, S-VIDEO, Complex, YUV etc. It can display programs of video, image, text. Displaying every information by real time, synchronous,clear message and can show two or three dimension animation, video, TV, VCD program and live broadcast.
Features of P4 Indoor Die Cast LED Display:
Use SMD technology to make the LED display have good video effect.
Synchronously adjust the brightness and color to make the true and exquisite image.
High contrast, high refresh rate make the image without any delay, trailing smear.
Compatible to many signal sources such as AV, S-Video, DVI, VGA, YPbPr, HDMI,SDI,DP etc.
Special wooden Case package protect the whole screen system.
PCB patent technology, the most stable signal transmission technology in the world.
Combine perfect design and stage of the art technology for united cabinet screen with simple appearance, compact strcture, stable performance
P4 Full Color rental indoor led display
1. High Refresh
2. High Resolution
3. Competitive price and Good quality
4. Easily to Install and Dismantle
5. CE,ROHS,CCC, ISO9001
