Guangzhou Sanway Professional Audio Equipment Co., Limited >> High Quality Light Power Amplifier Audio (FP10000Q)

High Quality Light Power Amplifier Audio (FP10000Q)

High Quality Light Power Amplifier Audio (FP10000Q)
Price: US $ 500-1000/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: T/T,Paypal,Western Union
Prod Model: Sanway FP10000Q
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Fans: 2PCS 80X80X25mm and 2PCS 60X60X15mm
Signal-to-Noise Ratio: >112 Dba
Type: Professional Amplifier
Usage: KTV System
Used For: Professional
Tube Type: Transistor Amplifier
Function: Amplifier Combined
Sound Channel: 4.1
Output Number: 4
Voltage: AC 220V
Element Number: Push-Pull Amplifier
Conductive Mode: Td Class

Product Description

FP10000Q High Quality Light Power Amplifier Audio

Output Power 20-20kHz, 1W with 1 kHz
8Ω Stereo Power(RMS): 1350WX4
4Ω Stereo Power(RMS): 2100WX4
2Ω Stereo Power(RMS): 2500WX4
8Ω Bridged Power(RMS): 4200WX2
4Ω Bridged Power(RMS): 5000WX2

Specification
FP10000Q dj audio mixer line array Switching Power Amplifier
ITEMFP10000Q
Output Power20-20kHz, 1W with 1 KHz
8ΩStereo Power(RMS)1350WX4
4ΩStereo Power(RMS)2100WX4
2ΩStereo Power(RMS)2500WX4
8ΩBridged Power(RMS)4200WX2
4ΩBridged Power(RMS)5000WX2
Frequency Response(+o/-0.3dB,1W/8Ω)20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W<0.1%
Signal-to-Noise Ratio>112 Dba
Channel separation (Crosstalk) at 1 kHz>70 dB
Input Connectors (per channel)3-pin XLR, electronically balanced
Output Connectors (per channel)Binding Posts 2-pole
ClassTD
TourClass Protectionshort circuit, DC voltage, turn-on/off transient, current, inrush
Operating voltage130-265 V / 65-135 V selectable
Voltage Gain(dB)23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance20 Kohms
Level adjustment (per ch.)Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions (W×H×D)483×88×396mm
Packing dimension560×180×500mm
Net weight(kg)12
Gross weight(kg)18

Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.

With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.

Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.

Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.

Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.

We always keep and follow the principle to do business:

The same product, we win by the quality;

The same quality, we win by the price,

The same price, we win by the service.

We sincerely hope that continuous business relationships can be established and please trust that we are always doing our best to realize good business relationships with our clients. We are constantly seeking new agents and distributors worldwide.

Don't hesitate to contact us if you are interested in any item, or should you have any special requirement, please kindly let us know directly, we will reply you as soon as possible.
