High Production Bagging Industrial Ice Maker From Snowell

Prod Model:	ZB5T
Product Name:	10t Tube Ice Maker
Compressor Brand:	Bitzer or Bock
Compressor Refrigeration Capacity:	74.3kw
Operating Power:	29.8kw
Installation Power:	40kw
Tube Ice Temp.:	-10°c
Tube Ice Diameter:	29mm
Condensing Temp:	42°c
Design Ambient Temp:	35°c
Design Water Inlet Temp.:	25°c
Certification:	CE
Condition:	New
Ice Shape:	Tube Ice

Product Description

high production bagging industrial ice maker from Snowell

As the name implies,tube ice maker makes tube ice,which is a kind of hollow cylindrical ice with external diameter normal Φ29mm and length 25-42mm,. the hole diameter usually 5-10mm and it can be adjusted according to ice making time.

Tube ice can be white color or crystal. Compare with flake ice,tube ice has longer melting time.


Features of our tube ice maker

1. Perfect design: this tube ice machine adopts 3D simulation assembly, compact structure, easily operate and maintain.

2. Our tube ice machine adopts the newest international ice machine making technology. Equipped with world famous components like Bitzer Compressor, Danfoss Expansion Valve, and so on.

3.User-friendly design for the tube ice maker ,very convenient for operator.

4.Saving energy and low maintenance and operation cost. After the tube ice is off, the water of low tempreture is used for ice making,increasing the volumn of production fo ice.

6.All the material of the tube ice maker meets the HACCP request. CE, ISO Certificate approved. The use of stainless steel SUS304, aluminium alloy plate type evaporator,accords with the health and safety requuiments.


Application of tube ice makjer

1. Freezing drinks, mix wines. cool foodstuffs, make ice pastries and keep fresh.

2. Widely used in hotel, bar , restaurant, catering, supemarket, ballroom, etc.

3. Food production process.

4. Chemical industry process, etc

5. Fish industry

6.Slaughterhouses and related packing industries


Features of the 10T tube ice maker

Following diameter is just for reference. Any different request,please let me know. We will manufacture the machine accordingly.


Additional 10T/24hrs Tube Ice maker Parameters
No	Description	Specification
1	Design Production Capacity	10T/24hrs
2	Refrigeration Capacity	51.7 kw
3	Refrigerant	R22,R404A ect
4	Operating Power	29.8kw
5	Inner Diameter of ice tube	3mm-15mm



After-sales Service for the tube ice maker

1. Two years warranty

2. Offer Spare parts free of charge within the warranty period.

3. Technical Documents

When beyond the warranty, Snowell will supply the parts and service only for factory price.



Frequent Asked Questions(FAQ)

Q1: What is the delivery time?

A1:
   1).The ice making machine type. Our main product line includes Flake Ice maker, Tube Ice maker, and Block Ice maker. The manufacturing is totally different. So the time and effort spent on these machines varies. Normally the flake ice machine is fastest under the same ice daily capacity

   2). Different Ice Daily Capacity: we have 1T, 2T, 5T, 10T, 20T, 25T, 30T, 40T, 50T ice making machines. For small capacity ice making machines(like1-5 tons), it needs about 10-15 working days. For larger capacity ice machines, it needs around 20-30 working days).


Q2. What is the payment terms and trade terms?

A2: Normally, we accept T/T, 30% Deposit and 70% balance paid before delivery.
      Trade Terms: FOB Shenzhen


Q3: Do I need to install the ice machine by myself?

For small ice machine, we ship it as a whole unit. So you just need to prepare power and water to run the machine.

For some larger ice machine plant, we need to keep some components separate for shipping convenience. But no worries about that. An installation brochure will be sent to you, it's very to install the machine.


Q4: For Water Cooled and Air cooled Machine, Which one is better?

A4: It depends. If the electricity is more abundant and cheaper than water, air cooled one is recommended. Likewise, you can choose the water cooled one according to the situation.
