Sayi Electrical Appliance Co., Ltd. >> Hhf Series Hi-Pressure Axial-Flow Fans

Hhf Series Hi-Pressure Axial-Flow Fans

Hhf Series Hi-Pressure Axial-Flow Fans
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union
Prod Model: HHF
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: 3.5-16
Voltage: 110V/230V/380-450V
Certification: CE
Electric Current Type: AC
Mounting: Duct Fan
Blade Material: Cast Iron

Product Description

Product Description:
The HHF series hi-pressure axial-flow fans have the advantages such as hi- pressure,high efficiency,little area-occupying,easy-installation etc,they are widely used in the occasions where hi-pressure is needing.














Fan Number Rotation Speed Volume Flow Total Pressure Power Noise Weight
N o rpm m 3 /h Pa KW dB(A) Kg
3.5 2900 3350-4225 420-280 0.75 78 77
1450 1675-2112 105-70 0.25 67
4 2900 3800-5500 450-300 1.5 79 88
1450 1900-2750 110-75 0.37 68
4.5 2900 6120-8500 670-410 2.2 84 99
1450 3060-2100 167-102 0.37 73
5 2900 6820-9820 750-510 3 86 110
1450 3410-4910 190-130 0.55 75
5.5 2900 10900-15200 621-398 4 86 115
1450 5450-7600 155-100 0.55 75
6 2900 13200-16090 760-510 5.5 86 164
1450 7150-8650 170-130 0.75 75
6.5 1450 15300-21500 680-425 5.5 88 170
960 10130-14235 298-187 1.5 80
7 1450 18910-24380 730-600 7.5 88 208
960 12520-16140 320-270 3 80
8 1450 26010-31420 720-600 7.5 89 216
960 17220-20800 320-260 5.5 80
9 1450 27610-33510 840-560 11 90 250
960 18220-22190 370-250 7.5 81
10 1450 35000-45700 770-630 11 90 300
960 24020-30260 340-280 7.5 81
11 1450 48500-51550 690-580 15 92 380
960 36380-38660 370-330 7.5 83
12 960 57750-62760 740-620 18.5 93 480
720 43310-47070 420-350 7.5 84
13 960 56030-74710 810-600 18.5 94 520
720 42020-56030 450-340 7.5 85
14 960 63312-85511 812-612 22 95 590
720 47484-64133 458-344 11 85
15 960 76040-101390 820-620 22 95 650
720 57230-76040 460-350 11 85
16 960 91210-120233 912-652 30 96 740

SAYI electric Co., Ltd is located at east sea, and the traffic is very convenient. It's near to 104 national high way and the exit of yongtaiwen speedway. It's about 18km from taizhou airport, Daxi town is a very important town in the southern industry of taizhou city as the enviroment is graceful and the hills are beautiful as well as the putuo mountain in the east.

The site area of our company is 30, 000m2, while the building area is 50, 000m2. The registered capital of our company is USD12, 000, 000, the capital asserts is 50 million and the current assets is 60million. We have more than 500 staffs, which of them are over 80 of advanced, secondary and primary professional technical staffs. Our company is member of fan guild of China, which professional research, produce, sale and service the industrial fan series products.

The Max, capital of SAYI is the"person with ability"and "famous brand name". Our company has abundant technical force and topping testing center, R and D center, mould process center, modem standard plant and the advanced peoduction line and large equipemtn(including painting production line, electrophoresis line, numerical control plasma, fast assemble line, utomatic and fast punch and automatic winding equipment).

SAYI is based on the advanced of science and technology and the unique management concept, carrying our the quality management system of ISO 9001: 2000 widely, and the products carrying out the IEC standard, so the qualityis improving that our company is enlarging ceaselessly.

In the recently few years, we nearly cooperate with scientific research branches and colleges. We have been provided with ability of design testing set., Moreover we mainly based on the industrial fan, and our sales network is all over the wolrd.

Welcome all the customers of the world to do business with us, we are looking forward to create the resplendence with you.
