Shenzhen Xin Song Xia Automotive Electronics Co., Ltd. >> HD Upgrading Android System with GPS Navigator (JVC, 800*480)

HD Upgrading Android System with GPS Navigator (JVC, 800*480)

HD Upgrading Android System with GPS Navigator (JVC, 800*480)
Price: Negotiable/Piece
Trade Terms: FOB
Min Order: 10/Set
Pay Type: T/T,Western Union,Paypal
Prod Model: LLT-JV3315
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Navigation Host Size: 148*118*40(Mm)
Gr. Wt: 0.75kg
RAM: 1GB Ddriii
Flash: 8GB
U Flash Disk: 8GB
Antenna Current: 27db
Maximum Height Positioning: 18, 000m
Tracking Sensibility: -159dBm
External Antenna Interface: SMA
Frequency: 1.575GHz
Certification: ISO
Video Output: VGA
Audio Output: Digital Optical Output
Voltage: 12/24V
Placement: Dashboard
Combination: TV

Product Description

HD/800*480 Android Box, Android Navigator,Android Unit/Android unit system,GPS Android Box installed Original car Unit for Pioneer/Sony/JVC with
AVH 1650, 2650, 4650, 5650, 8650,AV61, AV71, V10, V20, V40,DDX630, DDX630BT,Toyota Prius 10-30


The Best
Super-strong Dual-core processor: Cortex A8 1.2GHz
The Strongest compatibility: Match up with different screen and display affection
Maximum Video formats: AVI (H. 264, DIVX, DIVX, XVID, rm, rmvb, MKV (H. 264, DIVX, DIVX, XVID), WMV, MOV, MP4 (H. 264, MPEG, DIVX, XVID), MPEG, MPG, FLV (H. 263, H. 264)
Support maximum 32G external U Flash Disk and Hard Disk



Support Maximum 32G external TF/SD card
Operating system: Android 4.2/4.4 more stable!
Support varieties of resolution, Maximum 800*480
Support TMC (TRAFFIC MESSAGE CHANNEL)
External E-dog with Full frequency radar LDT
Support touch screen control, and share a touch screen
Reset the factory settings



Wi-Fi Hotspot Tethering, Wi-Fi wireless Internet and 3G Internet
USB 2.0 OTG HOST port which can connect computer and storage space can connect this machine. Vast of Audio format: WAVE, AIFF, AU, MP3, MIDI, WMA,
RealAudio, VQF, OggVorbis, AAC, APE; Support AVIN




SYSTEM PARAMETER
Frequency 1.2G~1.5G Hz
Chip A20
RAM 1GB  DDRIII
Storage space 8GB NAND Flash
Navigation software storage SD/TF card
Operating system Android 4.2/4.4
Multimedia and Performance
Audio WAVE\AIFF\AU\MP3\MIDI\WMA\RealAudio\VQF\OggVorbis\AAC\APE
Video AVI(H.264, DIVX, DIVX, XVID, rm, rmvb,  MKV(H.264, DIVX, DIVX, XVID), WMV, MOV, MP4(H.264, MPEG, DIVX, XVID), MPEG, MPG, FLV(H.263,H.264)
Audio interface performance 1080P HD Video playback
Image browser
Map Type BMP/JPG/GIF/PNG
                                                                                        Text-based browser
Text Type TXT
Internet
Network Type EVDO/W-CDMA/Wi-Fi
Network speed 7.2M/S
GPS Hard Software
CS SIRF IIIOR U-BLOX 6
Frequency 1.575GHZ
C/A CODE 1.023 MHZ chip rate
Port numbers 20
Tracking sensibility -159dBm
Positional accuracy 10m, 2D RMS
5m, 2D RMS, WAAS enable
Rate  0.1m/s
Date updating rate 1HZ
Capture time Average 0.1s(OPEN SKY)
Hot boot time Average 3s(OPEN SKY)
Warm boot time Average 38s(OPEN SKY)
Clod boot time Average 45s(OPEN SKY)
Maximum height positioning 18,000m
Maximum rate 515m/s
Acceleration < 4g
External antenna interface SMA
External antenna voltage 3.3V±5%
External antenna gain 27dB
External antenna current 15mA
USB Parameter and Performance
USB interface Type USB 2.0(High Speed)Device
USB Performance Connect PC, Support U Flash Disk


Shenzhen Xin Song Xia Automotive Electronics Co., Ltd established in 2009. The

Company is located in the advanced southern metropolis --- Bao'an District, Shenzhen city. It covers 60 staffs, including 10 R&D persons. It has 5 production lines and 1 production line for old product.

Company attaches great importance to research and develop new products. We have launched many new solutions for car models such as Mercedes-Benz, BMW, Audi, Honda, GM), etc. And with the ability of producing 50000 sets of original screen entertainment production per year.

We regard quality as life. The company equipped with many test equipment at the world's advanced level such as experiment box, vibration tester, high and low temperature boxes, ESD static tester, power supply fluctuation test instrument, Sound and video automatic detector. And we have made a strict quality inspect system and process. Operating comply with international quality system certification such as ISO9001: 2000, ISO/TS16949: 2009 etc. Strictly.

Shenzhen Xin Song Xia Automotive Electronics Co., Ltd sticks to the Traditional spirits "Create Classic attentively" and Enterprise culture "Creative, Flexible, Team, and Mutual Benefits" which consistently Challenge Himself, The Best of the Best as Conducts to Create more wonderful products to satisfy Driver for Car audio system entertainment

Our products are not only providing Inland 4S Shop, but only the supplier of South America, Middle East, Europe, and America at abroad. Company owed Sales network through the country and Contact the strategy Cooperation relationships with more than 10 Car sales CO.

Develop and Grow is common goal of members. Bellwether of Supplier of OEM Car audio upgrading kit is our Grand mission to the world.
