Guangzhou Sanway Professional Audio Equipment Co., Limited >> Guangzhou Switching Power Amplifier Fp10000q

Guangzhou Switching Power Amplifier Fp10000q

Guangzhou Switching Power Amplifier Fp10000q
Price: Negotiable/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: T/T,Western Union
Prod Model: Sanway FP10000Q
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Function: Post Amplifier
Tube Type: Transistor Amplifier
Voltage: AC 220V
Element Number: Push-Pull Amplifier
Output Number: 4
Used For: Professional
Usage: KTV System
Sound Channel: 4.1
Conductive Mode: Td Class

Product Description

Guangzhou Switching Power Amplifier FP10000Q Specification
Output Power 20-20kHz, 1W with 1 kHz
8Ω Stereo Power(RMS): 1350WX4
4Ω Stereo Power(RMS): 2100WX4
2Ω Stereo Power(RMS): 2500WX4
8Ω Bridged Power(RMS): 4200WX2
4Ω Bridged Power(RMS): 5000WX2

1.4X2500W@2ohm Audio Power Amplifiers
2.13KG Lightweight Switching Power Amplifiers
3. FP10000Q High Power Amplifiers, Professional Pro Audio Power Amplifiers

Applications

1>. Arenas, Nightclub
2>. Convention Centers
3>. Medium or large Ballrooms
4>. Perfect for corporate
5>. Theaters Music
6>. Disco, Club or Church
7>. Concert reinforcement

Specifications:
FP10000Q Professional Amplifiers Audio for Sale
ITEM FP10000Q
Output  Power 20-20kHz,   1W  with  1  KHz
8Ω Stereo  Power(RMS) 1350WX4
4Ω Stereo  Power(RMS) 2100WX4
2Ω Stereo  Power(RMS) 2500WX4
8Ω Bridged  Power(RMS) 4200WX2
4Ω Bridged  Power(RMS) 5000WX2
Frequency  Response(+o/-0.3dB, 1W/8Ω ) 20  Hz  -  34  kHz
THD  20  Hz  -  20  kHz  for  1  W < 0.1%
Signal-to-Noise  Ratio > 112  Dba
Channel  separation  (Crosstalk)  at  1  kHz > 70  dB
Input  Connectors  (per  channel) 3-pin  XLR,   electronically  balanced
Output  Connectors  (per  channel) Binding  Posts  2-pole
Class TD
TourClass  Protection short  circuit,   DC  voltage,   turn-on/off  transient,   current,   inrush
Operating  voltage 130-265  V  /  65-135  V  selectable
Voltage  Gain(dB) 23,   26,   29,   32,   35,   38,   41,   44  dB  selectable
Input  impedance 20  Kohms
Level  adjustment  (per  ch. ) Front-panel  potentiometer,   31  position  detented  from  -inf  to  0  dB
Dimensions  (W× H× D) 483× 88× 396mm
Packing  dimension 580× 180× 560mm
Net  weight(kg) 13
Gross  weight(kg) 18
Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.

With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.

Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.

Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.

Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.

We always keep and follow the principle to do business:

The same product, we win by the quality;

The same quality, we win by the price,

The same price, we win by the service.

We sincerely hope that continuous business relationships can be established and please trust that we are always doing our best to realize good business relationships with our clients. We are constantly seeking new agents and distributors worldwide.

Don't hesitate to contact us if you are interested in any item, or should you have any special requirement, please kindly let us know directly, we will reply you as soon as possible.
