Full Color Indoor LED Screen&Indoor Rental LED Display
Price: |
US $ 1345/Square Meter |
Trade Terms: |
FOB,CIF,EXW |
Min Order: |
1/Square Meter |
Pay Type: |
T/T,Western Union |
Prod Model: |
P5 Full Color Indoor LED Screen&Rental LED Display |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Module Size: |
160*160 |
Cabinet Size: |
640*640 |
Cabinet Material: |
Iron or Aluminum |
Display Type: |
LED Video Display |
Tube Chip Color: |
Full Color |
Display Function: |
Video Display |
Scanning Mode: |
1/16 Scan |
Certification: |
CCC |
Pixel Configuration: |
1R,1G,1B |
Pixel Pitch: |
5mm |
Pixel Density: |
40,000 dots / m² |
Application: |
Shopping Guide |
IP Rating: |
IP43 |
System Operating Platform: |
WIN XP |
Product Description
P5 Indoor Full Color LED Screen 1.large viewing angle2.High brightness3.Light weight4.Convenient to install and dismantle5.Famous IC brand ensure the quality6.Long life span Export Markets:South America,North America,Oceania,Mid East,Africa,Western Europe,Southeast Asia Our products cover indoor and outdoor full color LED screen, cabinet module, panel etc;P5 Full Color SMD3528 Indoor Module |
Item | Unit | Parameter |
Pixel Pitch | mm | 5.00 |
Resolution of Module | dots | 32x16 |
Module Size | mm | 160x80 |
Module Weight | kg | 0.25 |
Pixel Configuration | SMD3528 1R1G1B |
Chip Brand of LEDs | Epistar |
Pixel Density | dots/sqm | 40,000 |
Brightness (White Balance) | nits(cd/sq.m) | ≥2000 |
Red Wavelength | nm | 620-625 |
Green Wavelength | nm | 520-525 |
Blue Wavelength | nm | 470-475 |
Scan Mode | 1/16 Scan |
Viewing Distance | M | 3--35 |
Best View Distance | M | 5--15 |
Viewing Angle-Horizontal | deg. | 120 |
Viewing Angle-Vertical | deg. | 120 |
Module Maximum Power | W | 25 |
Max. Power Consumption | W/sq.m | 1,000 |
Avg. Power Consumption | W/sq.m | 300 |
Working Voltage | 5V 40A |
Power Supply | AC 110/220V |
Refresh Rate | Hz/S | 3,000 |
Frame Rate | Hz/S | ≥60 |
Gray Scale | 4096 grades gray |
Display Function | Text,news,advertising,flash,animation |
Input Signal | RF,S-Video,RGB,RGBHV,YUV,YC,SDI,HD-SDI,DVI,UXGA,COMPOSITION,etc. |
Luminance Degradation | Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25 centigrade. |
Defective Dot Rate | <0.0001 |
Life Span | hours | 100,000 |
MTBF | hours | >5,000 |
Storage Temperature | centigrade | -35 -- +80 |
Working Temperature | centigrade | -20 -- +60 |
Control System | Synchronization or Asynchronization |
Quality Certificate | CE,CCC,ISO9001,ROHS |
Warrenty | 2 Years |
Working Environment | Indoor |
Rental LED Display Function: 1.Video Broadcast Functions 2.Information dissemination functions 3.Network functions Good after-sale-service for customers:1. Noveled Group provide pre-sale service in technical consultation such as recommend and design solutions for the customers' requiements,which can help increase the risk of customers' investing;2. We accept customers supervision during production;3. We also provide necessary training to customers;4. We will take great responsibility to collect customers' feedback,inspection and maintain products periodically to ensure solving problems timely.
