Fp10000q Professional Power Amplifier

Fp10000q Professional Power Amplifier
Price: US $ 500-1000/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: T/T,Western Union,Paypal
Prod Model: Sanway FP10000Q
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimension(Wxhxd): 483X88X396mm
Class: Td
Type: Professional Amplifier
Function: Pre-amplifier
Usage: KTV System
Voltage: AC 220V
Element Number: Monoamplifier
Output Number: 4
Used For: Professional
Tube Type: Transistor Amplifier
Sound Channel: 4.1
Conductive Mode: Td

Product Description

FP10000Q Professional Power Amplifier

1. 10000W Audio Power Amplifier
2. Lightweight Switching Digital Power Amplifier
3. FP10000Q Class TD High Power Amplifier




Specifications:
FP+ series Switching Power Amplifier Specification
ITEMFP7000FP9000FP13000FP14000FP6000QFP10000Q
Output Power                                    20-34kHz, 1W with 1 khz
8ΩStereo Power(RMS)1450WX21600WX22350WX22350WX2625WX41350WX4
4ΩStereo Power(RMS)2800WX23000WX24400WX24400WX21250WX42100WX4
2ΩStereo Power(RMS)3500WX24500WX26500WX27000WX21500WX42500WX4
8ΩBridged Power(RMS)5600W6000W8800W8800W2500WX24200WX2
4ΩBridged Power(RMS)7000W9000W13000W14000W3000WX25000WX2
Frequency Response(+o/-0.3dB,1W/8Ω)20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W<0.1%
Signal-to-Noise Ratio>112 dBA
Channel separation (Crosstalk) at 1 kHz>70 dB
Input Connectors (per channel)3-pin XLR, electronically balanced
Output Connectors (per channel)Binding Posts 2-pole
ClassTD
TourClass Protectionshort circuit, DC voltage, turn-on/off transient, current inrush
Operating voltage130-265 V / 65-135 V selectable
Voltage Gain(dB)23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance20 kOhm
Level adjustment (per ch.)Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions (W×H×D)483×88×396mm
Packing dimension560×180×500mm
Net weight(kg)13
Gross weight(kg)18

Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.

With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.

Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.

Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.

Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.

We always keep and follow the principle to do business:

The same product, we win by the quality;

The same quality, we win by the price,

The same price, we win by the service.

We sincerely hope that continuous business relationships can be established and please trust that we are always doing our best to realize good business relationships with our clients. We are constantly seeking new agents and distributors worldwide.

Don't hesitate to contact us if you are interested in any item, or should you have any special requirement, please kindly let us know directly, we will reply you as soon as possible.
