Dongguan HRSC PCB Co., Ltd. >> FM Transmitter PCB Printed Circuit Board

FM Transmitter PCB Printed Circuit Board

FM Transmitter PCB Printed Circuit Board
Price: US $ 0.1/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Paypal,Money Gram
Prod Model: pcb-0064
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Layer No.: 1-16
Cooper Thickness: 0.5 Oz-11oz (18 Um-385 Um)
Finished Board Thickness: 0.2 mm-3.8mm'(8 Mil-150 Mil)
Certificate: RoHS, ISO9001:2008, SGS, UL Certificate
Laminate Materials: Fr-4,Fr-1,,Fr-2,Cem-1,Cem-3
Type: Rigid Circuit Board
Dielectric: FR-4
Material: Fiberglass Epoxy
Flame Retardant Properties: V0

Product Description

We are the Printed Circuit Boards(PCB) manufacturer with 15 years experience, specialized in single-sided, 2-layerd, multilayer and high density interconnector (HDI) PCB.

Certification: UL, ISO14001, ISO9001, SGS, TS16949
Used for auto industry, high power led, electric toy, machinery, industrial lighting and so on.

Our process capability
DescriptionCapability
PCB Surface Finisheselectrolytic nickel-gold,
HASL(Lead Free, ENIG (Electroless Nickel/Immersion Gold, Carbon Ink, Golden Fingers, OSP (Entek, Immersion Tin, Immersion Silver
PCB Board Max. Size 1200mm×600mm
PCB Board Min. Size 5mm×5 mm
Bow & Twist Tolerance Single Side≤1.0%,Double Side≤0.7%, Muti-Layer≤0.5%
Min. Board Thickness & Tolerance 0.2mm±0.08mm
Min. trace/spacing Tin board:0.2mm±20%(8mil±0%)
 gold board:0.075mm±20%(3mil±0%)
Copper to Board Edge Spacing 0.5mm(20mil)
Hole to Trace Spacing 0.3mm(12mil)
Min. Hole Diameter 0.2mm±.076mm(8mil±3mil)
Min. Hole Clearance 0.4mm±.076mm(16mil±3mil)
Copper Thickness on Hole Wall 20-25um(0.79mil-1.0mil)
Hole Location Tolerance ±0.076mm(l±3mil)
Min Diameter of Punching Hole FR-4 board thickness≤1.0mm(40mil):1.0mm(40mil)
 FR-4 board thickness 1.2-3.0mm(48-120mil):1.5mm(60mil)
Min. Punching Slot FR-4 CEM-3 board thickness≤1. 0mm(40mil):0.8 mm×0.8 mm(32mil×32mil)
 FR-4 board thickness1.2-3.0mm(48-120mil): 1.0 mm×1.0 mm(40mil×40mil)
Trace width variation ±0.076mm(±3mil)
Outline Tolerance Routing:±0.1mm (±4mil)  ,Punching:±0.05mm (±2mil)
V-CUT Registration Tolerance±0.2mm (±8mil)
TypeSingle-sided, double-sided, multi-layer
Major Material FR-4, CEM-1,CEM-3, high frequency laminates, Aluminum, NiFe-based, copper base
Thickness 0.2-3.5mm
Base Copper Thickness 11um  35um  70um  105um
Max. aspect ratio(board thickness: hole size) 8:1
V-Cut Angle Tolerance ±5°
V-Cut Board Thickness 0.4mm -3.2mm(16mil -128mil)
Min SMT Pitch 0.3mm(12mil)
Min. Component mark 0.15mm(6mil)
Min. width of annular ring(finished) 0.15mm(6mil)/side
Min pad opening 0.076mm(3mil)
Min S/M Bridge ±0.076mm(±3mil)
 carbon ink board manufacturing capability:1.Impedance Control:20K±10%  2.Hardness:6H  3.bearable friction times :above 200000 times
What we need:
 Please tell us the information as below:
Board for what productSurface Finish
Number of LayersBoard Material
Copper Thickness(um)Board Thickness(um)
Solder Mask ColorPCB Dimensions(mm)
Silk Screen ColorMin Finished Hole Size(mm)
MillingMin Clearance(mm)
Min Track Width(mm)Other special requirements

Fast delivery:
PackagingVacuum Packing with desiccant,
Professional Export Carton.




Delivery
time


Prototype   Mass production
(above 30m)
2LQuick turn:24h
Usual time:3-4days
5-10days
4LQuick turn:48 hours;
Usual time:5-6days
8-15days
6LQuick turn:72 hours;
Usual time:6-8days
10-16days
8LQuick turn:72 hours;
Usual time:8-10days
16-18days
10LQuick turn:96 hours;
Usual time:12-14days
18-20days
``````

Please send us your Gerber Files and PCB specifications; we will quote for you within 12 hours.

We always try our best! So we do, we conquer, and we get there!

Contact us!!

Dongguan HRSC PCB Co., Ltd is a professional printed circuit board¨ PCB© Manufacturer with 15 years experience, specializing in single-sided, double-sided, multilayer and high density interconnector PCB, owning 100, 00 m2 factory, with 320 employee. Monthly output is 35, 000 m2.

HRSC has advanced processing equipments and highly skilled workers. Our products widely apply in lighting, electronic game machine, auto industry, communication equipment, computer peripheral product, medical devices, etc. The quality of products is highly praised by the industry. In 2013, we have introduced more advanced overseas brand machines, and strived to become fist-class PCB manufacturer.

We have successively obtained certification of UL, ISO14001, TS16949, passed SGS test. And meets RoHS and REACH standards. Then we are improving the management of market development, engineering design, manufacturing, quality assurance, after-sales service, and have enjoyed the industry good reputation and customers' trust. Presently our company has deeply trusted and well received by Japanese well-known enterprises and sino-foreign joint venture companies. To keep pace with the high-techn industries, HRSC always uphold the tenet "integrity, practical, innovation", exerting the advantages of market, technology and talents, to provide our customers with quality products and efficient service.
