| Prod Model: |
F1000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Supply Power: |
2350W |
| 8ohms Stereo Power(RMS): |
2X520W |
| Type: |
Professional Amplifier |
| Function: |
Post Amplifier |
| Tube Type: |
Transistor Amplifier |
| Voltage: |
AC 220V |
| Element Number: |
Push-Pull Amplifier |
| Output Number: |
4 |
| Used For: |
Professional |
| Usage: |
AV |
| Sound Channel: |
2.1 |
| Conductive Mode: |
3 Step H Class |
Product Description
F Series High Switching Professional Power Amplifier (F1000)
Description:
1.2x784W@4 ohms Stereo Amplifier
2. Reliable Professional Power Amplifier
3. CE&RoHS Certification Stereo Audio Amplifier
KEY FEATURE
1). 2/3U high, heavy duty steel chassis
2). Modular construction for easy servicing
3). Symmetrical layout for even weight distribution
4). High efficiency toroidal power transformer
5). Oversized, high energy, linear power supply
6). 3 steps, Class H Audio topology
7). Stereo, parallel or bridged operation
8). Twin balanced inputs (Neutrik® XLR connectors)
9). Dual Speakon® And Binding posts outputs
10). High quality components used throughout
11). Dual, continuously variable speed fans
12). Efficient DC fans cooling,
13). Active, signal, protect and critical indicators
14). Duraluminium, 8mm thick front-panel
15). Unobtrusive carrying handles
16). Voltage Gain: 35 or 40 dB
Specifications:
|
F1000 Power Amplifier |
|
8Ω Stereo Power(RMS) |
2× 520W |
|
4Ω Stereo Power(RMS) |
2× 784W |
|
2Ω Stereo Power(RMS) |
2× 1350W |
|
8Ω Bridged Power(RMS) |
1512W |
|
4Ω Bridged Power(RMS) |
2116W |
|
Frequency Response(+o/-0.3dB, 1W/8Ω ) |
20Hz-20kHz, -3dB@135kHz |
|
Power Bandwidth (rated power at 4Ω 1%THD+N) |
20Hz-20kHz, -. 1.1dB/+0dB |
|
TourClass Protection |
ACL, IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input |
|
THD+N (1kHz 1W ) |
< 0.05% |
|
SMPTE IMD (rated power. 60 Hz & 7kHz) |
< 0.01% |
|
Damping Factor ( 1KHz) |
250 |
|
Input CMRR (1kHz) |
> -60dB |
|
Voltage Gain (rated power @ 8Ω ) |
X35dB |
|
Input Sensitivity (rated power at 8Ω ) |
1.3V |
|
Input Impedance (balanced/unbalanced) |
20KΩ /10KΩ |
|
S/N Ratio (" A" weighted, full power at 4Ω ) |
100dB |
|
Crosstalk (" A" weighted, full power@4Ω ) |
> -70dB |
|
Class |
3 Step H |
|
Input Connectors (per channel) |
Female XLR (pin 2+, configurable for pin 3+). TRS (tip+) |
|
Output Connectors (per channel) |
5-way binding posts or Speakon connectors (market dependent) |
|
Supply Power |
2350W |
|
Power Supply (factory configured) |
AC220V/230V, 50-60Hz |
|
Cooling |
Two side panel variable speed DC fans, better than conventional cooling |
|
Controls |
Front panel: 2 attenuators, power switch; Rear panel: signal ground lift & mode switches. |
|
LED Indicators (per channel) |
Signal, Protect, Active, Critical |
|
Construction |
Steel chassis, 16 gauge . Casting Aluminum frontpanel . |
|
Dimensions (H× W× D) |
88× 483× 480mm (2U) |
|
Net Weight |
26.5kg |
|
Gross Weight |
30.3kg |
Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.
With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.
Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.
Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.
Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.
