| Prod Model: |
JPS-JA/H-58-28 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Water Heater |
| Pipe Material: |
Vacuum Tube |
Product Description
Solar water heaters -- also called solar domestic hot water systems -- can be a cost-effective way to generate hot water for your home. They can be used in any climate, and the fuel they use -- sunshine -- is free.
How They Work
Solar water heating systems include storage tanks and solar collectors. There are two types of solar water heating systems: Active, which have circulating pumps and controls, and passive, which don't.
Active Solar Water Heating Systems
Evacuated-tube solar collectors
They feature parallel rows of transparent glass tubes. Each tube contains a glass outer tube and metal absorber tube attached to a fin. The fin's coating absorbs solar energy but inhibits radiative heat loss. These collectors are used more frequently for U. S. Commercial applications
Solar vacuum tube with heat pipe
1. Size: Φ 58X1, 800 mm
2. Quantity: 15 / 20 / 24 / 30 / 36 / 40 / 60 PCS
3. Temperature insulation layer
4. Using polyurethane bulk bubble and has a good effect of temperature preservation
5. Capacity: 150 / 200 / 300 / 500 L
6. Max. Pressure bearing: 0.6Mpa
7. Hail resistance: 25mm
Solar water collector:
A. Module design, arbitrary combination, harmonize with the building perfectly
B. Intelligent control and automatic operation
C. Anti-freeze: Using the anti-freezing liquid as the medium and the controller Has The anti-freezing function
D. Multifunction: Bathing, washing, domestic heating etc.
E. Work at anytime and enjoyable.
Material of Model:
1) The pipeline is made of red copper and conducted by heat transfer medium Liquid
2) Temperature preservation is equipped with standard electric water heater Setting, Automatic temperature control exchanger, and increased anode magnesium bars Sticking to prevent furring
3) The insulating layer uses polyurethane bulk bubble and has a good effect of Temperature preservation
4) Water tank (interior): Stainless steel inner tank
5) Manifold: Aluminum alloy out casing & red copper flow passage
6) Glass tube: New trivalent element heat tube, borrosilicate glass 3.3
7) Solar working station
8) With heat pipe: Anti-freezing > -35 degrees centigrade
9) Water capacity: 150L, 200L, 250L, 300L, 500L
10) Pressure: 6 Bars
11) Daily efficiency: >= 55%(>=42% in winter)
12) Heat preservation: 72h to 80h
13) Electric heater: 1.5Kw to 3Kw
|
Modules |
JPS-JA/H-58 -20
20 Tubes |
JPS-JA/H-58 -30
30 Tubes |
Type
Certificate, performance test
Shape of absorber |
All Glass Evacuated Tube Collector with Heat-Pipe
pr EN 12975-2
Ref. No.
cylindric |
Number of tubes
Active absorber area
Aperture area
Gross area
Length x width x height (mm)Liquid
contents |
20
2, 4 m²
1, 9 m²
2, 9 m²
1980x1450x165
approx. 60 Kg |
30
3, 6 m²
2, 8 m²
4.3 m²
1980x2150x165
approx. 90 Kg |
Glass material
Glass tube diameter (outer tube)
Glass tube diameter, (inner tube)Wall thickness
Vacuum
Absorber material
Coating
Absorption coefficient
Emission coefficient
Tilt angle
Test pressure
Permissible operating pressure
Max. Idle temperature of module Max. idle temperature of tube |
high-grade boron silicate hard glass
58 mm
47 mm
1.5 mm
< 10 -5 mbar
glass
selective coatedALN
92%...96%
8%...12%
15 to 90°
10 bar
6 bar
200 ° C
250 ° C |
