| Prod Model: |
EM-1028 |
| Item: |
Earbuds Earpiece for Cassidian Eads Th1n |
| Communication: |
Wired |
| Applicable: |
General, Hospitality, Hotels, Police, etc |
| Voice: |
Loud and Clear |
| Styles: |
in-Ear Earpiece |
| Useage: |
Two Way Radio Communication |
| Warranty: |
10 Months |
| For Radios: |
Th1n |
| Ptt Microphone: |
Yes |
| Cable Material: |
PU with Kevlar |
| Style: |
In-ear |
| Line-Control: |
Line-Control |
| Microphone: |
With Microphone |
| Type: |
Electret Earphone |
| Function: |
Noise-Cancelling |
| Earpad Size: |
Small |
| Color: |
Black |
| Wire Material: |
PU |
| Jack Type: |
All Radios Connectors Available |
| Use: |
Two Way Radios/Walkie Talkies |
Product Description
Earbuds Earpiece for Cassidian EADS TH1n digital two way radio
TH1N Connector:
Enhance your ease of communication with this headset equipped with a speaker / mic jack. The earpiece offers hands-free operation and operates with a push-to-talk button.
Adjustable rubber ear loop
Earhook earpiece, optional vox switch
Integrated Push-To-Talk microphone
All connectors available
Descriptions: 1.compatible for all brand radios.
2.adjustable rubber ear hook design makes it suitable for all kinds of ear and long time wearing.
3.feature heavy grade industrial jacketed cables and excellent strain relief for maximum life.
4.high quality earphone provide excellent transmitted and private communication.
5.with #28 small lapel PTT.
6.design for general , hospitality and entertainment markets
Speaker Specification
Type |
Transducer Moving coil dynamic speaker |
Impedance |
90Ω±15% @1KHZ |
Sensitivity |
110±3dB @1KHZ |
Resonance freq |
(F0) 400HZ±20% |
Frequency respond |
F0~5KHz |
Rated input power |
500mW |
Maximum input power |
800mW |
Microphone Specification
Sensitivity Range |
-34 ± 2dB RL=2.2K ΩVs=3.0V(DC) 1KHz 0dB=1V/Pa |
Impedance Max |
2.2KΩ 1kHz (RL=2.2KΩ) |
Frequency |
20-20KHz |
Current Consumption Max |
0.5uA RL=2.2KΩ Vs=3.0V(DC) |
Operation Voltage Range |
1.0V-10V (DC) |
Max Sound pressure Level |
115dB S.P.L
|
