| Prod Model: |
EM-3027C |
| Item: |
Ear Hook Earpiece for Motorola Cp040 |
| Communication: |
Wired |
| Connector: |
Kenwood One Pin Connector |
| Applicable: |
General, Hospitality, Hotels, Police, etc |
| Voice: |
Loud and Clear |
| For Radios: |
Cp200/Cp040/Cp140/Cp1300/Dp1400/Ep450/Gp300/Gp308 |
| Shape: |
Swivel Earpiece |
| Warranty: |
10 Months |
| Cable: |
Coiled Cable |
| Receive And Transmit: |
Yes |
| Style: |
Ear Hook |
| Line-Control: |
Line-Control |
| Microphone: |
With Microphone |
| Type: |
Electret Earphone |
| Function: |
Microphone |
| Earpad Size: |
Small |
| Color: |
Black |
| Wire Material: |
PU |
| Jack Type: |
Kenwood K3 One Pin Connector |
| Use: |
Two Way Radios Communication |
Product Description
Ear hook Earpiece with soft rubber eartip for Motorola EP450/EP350/PR03150
Features:
1. G shape ear hook with soft rubber eartip;
2. PTT button with built-in microphone and clothing clip;
3. Superior performance earphone;
4. Molded strain reliefs help protect cables from excessive bending and pulling;
5. Design for General,Hospitality,Hotels and Entertainment markets.
Speaker Specification
Type | Transducer Moving coil dynamic speaker |
Impedance | 90Ω±15% @1KHZ |
Sensitivity | 110±3dB @1KHZ |
Resonance freq | (F0) 400HZ±20% |
Frequency respond | F0~5KHz |
Rated input power | 500mW |
Maximum input power | 800mW |
Microphone Specification
Sensitivity Range | -34 ± 2dB RL=2.2K ΩVs=3.0V(DC) 1KHz 0dB=1V/Pa |
Impedance Max | 2.2KΩ 1kHz (RL=2.2KΩ) |
Frequency | 20-20KHz |
Current Consumption Max | 0.5uA RL=2.2KΩ Vs=3.0V(DC) |
Operation Voltage Range | 1.0V-10V (DC) |
Max Sound pressure Level | 115dB S.P.L |
.
Note:Give us your radio model, we can give out our exactly suitable connector to compatible.
Company information:
Raytalk Communications Electronics Co., Ltd is a professional manufacture in two way radio accessories and Aviation Headset since 2003.
Our products include Aviation headset,heavy duty headset,PTT Selection,Lapel Microphones, Surveillance Kits,Earpieces,Ear bone Microphone,Handle Speaker Microphone,Throat Microphone,Boom microphone,Listening only kits,audio adapters,Spare parts etc, compatible with Motorola, Kenwood, Icom, HYT,Vertex,Nokia,Midland, Nexus, Simoco,etc. With an experienced and professional tean, our products have been exported to many countries and regions all over the world and enjoy high reputation among our customers.
Your one stop source for Two way radio accessories. (Safety & Comfortable Communication)
RayTalk Communications & Technology was established in 2003 as a professional manufacturer of two way radio Accessories & Aviation headsets, and has continued to provide worldwide customers with the best in two-way communications products and services/ Our team of sales, service, engineering and operations are among the most qualified and best trained in the two way radios industry.
Our products include audio accessories, headset, earpiece, surveillance kit, speaker microphone, throat microphone, batteries, battery chargers compatible with Motorola, Kenwood, Icom, HYT, Vertex/Standard, GME, Unider and Tait products.
RayTalk has delivered comprehensive, dependable, and cost-effective solutions to meet the demands of our clients and on site support service tailored to the specifications and budgets of our clients. OEM & ODM are also welcome, our teams of experts work closely with customers and listen to your opinions with an aim to create products that suits your requirements.
At RayTalk, we are committed to providing the highest level of customer service, competitive pricing, speedy delivery and a comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction. With the skill, range of service, stability and resources, we believe we can become your long-term communications partner.
