| Prod Model: |
KF120-A/320F |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Heat Source: |
Air-source |
| Certification: |
CE |
| Application: |
Villa Family |
Product Description
This type of Domestic Split Heat Pump adopts copper/ss316 coil heat exchanger inside/outside the pressurized water tank, supplying sanitary hot water for homes and residence.
Features
1. Intelligent defrosting
2. Famous brand rotary compressor
3. R22/R410A refrigerant
4. Horizontal fan discharge
5. Safe, reliable, stable running & durable
6. Concise design
7. Easy installation & operation
8. Intelligent controller
Optional:
1. Pressured water tank with external copper coil heating exchanger
2. Pressured water tank with internal copper/ss316 coil heating exchanger.
|
Model |
|
KF120-A/320F |
Heating capacity |
KW |
4.9 |
|
COP |
|
3.98 |
|
Water tank volume |
L |
320 |
|
Rated heated water output |
L/h |
105 |
|
Rated outlet water temp. |
° C |
55 |
|
Maxoutlet water temp |
° C |
60 |
|
Rated power input |
KW |
1.23 |
|
Rated current |
A |
5.89 |
|
Power supply |
Voltage/Hz/Phase |
220V/50Hz/1Ph |
|
Compressor type |
|
Rotary |
|
Number of Compressors |
|
1 |
|
Heat exchanger type |
|
Copper coil pipe |
|
Throttling device |
|
Capillary |
|
Fan type |
|
Low noise high efficiency axial type |
|
Fan discharge |
|
Horizontal |
|
Fan quantity |
|
1 |
|
Fan input |
W |
60 |
|
Fan speed |
RPM |
830 |
|
Ambient temperature |
° C |
(-10° C~43° C) |
|
Refrigerant |
|
R22/R410A |
|
Noise in 1 meter distance |
dB |
≤ 54dB(A) |
|
Water pipe size |
|
Rc3/4 |
|
Cabinet |
|
Steel with powder coated |
|
Low pressure protection system |
|
Yes |
|
High pressure protection system |
|
Yes |
|
Water flow switch |
|
No |
|
Automatic defrosting system |
|
Yes |
|
Product dimensions |
MM |
850× 260× 540 |
|
Packaging dimensions |
MM |
930× 370× 620 |
|
Product dimensions(water tank) |
MM |
555*1839 |
|
Packaging dimensions(water tank) |
MM |
620*640*1890 |
|
Net weight |
KG |
33 |
|
Gross weight |
KG |
38 |
|
Net weight(water tank) |
KG |
58 |
|
Gross weight(water tank) |
KG |
86 |
|
Testing condition |
Ambient temp. (DB/WB) = 20 ° C / 15° C, Inlet/outlet water temp. = 15 ° C /55 ° C |
