| Prod Model: |
ID-D1.5-Blue-Countdown Timer-A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| LED Digits Hight: |
1.5'' |
| Module Size: |
32.5*45mm |
| Thickness: |
55mm |
| Brightness(Mcd): |
4000 |
| Screen Size: |
310*180*55mm |
| Package Size: |
410*280*155mm |
| Nw(Kg): |
8.8 |
| Gw(Kg): |
9.5 |
| Color: |
Blue |
| Watts: |
8.1W |
| IP Rating: |
IP65 |
| Scanning Mode: |
Static Scan |
| Display Type: |
Segment LED Display |
| Certification: |
CCC |
| Tube Chip Color: |
Blue |
| Display Function: |
Time&Temp |
| Average Power Consumption: |
42W |
Product Description
POOSLED indoor or outdoor time &temperature LED Displays are ideal for attracting potential customers' attention to your business, while providing beneficial information to the community. Competitive price to give you outstanding value, while minimize your maintenance and energy costs. They can be used for advertising&entertainment, enquipment status display, transportation message, public message, bulletin board.
TECHNICAL FEATURES
1. Control system: POOSLED TIME&TEMP control system--RF Remote control/ RS232/485/ TCP/IP, making digits changes quickly and easily.
2. Outdoor or Indoor brightness available.
3. Display format: 88: 88 or 88: 88: 88 or customized.
4. Time display: Time(T)
5. Temperature display: Celsius(° C), Fahrenheit(F), the clients can change with remote controller.
6. Different sizes and colors are available that fit your flexible needs and wants.
7. A finished cabinet makes installation trouble-free with no additional fabrication needed.
8. Customized face designs.
9. Battery backup to retain the display's memory in case of power outages.
10. High intensity LEDs allow for us to manufacture a more efficient display.
11. Power supply are CHENGLIAN with CE certification and MEANWELL with UL certification.
| 88:88:88-8''-T&T |
| 1 | Sign's name | 88:88:88-8''-T&T |
| 2 | Item classification | led chips(12mil SANAN) |
| 3 | Color: | Red |
| 4 | Digit Height: | 8'' |
| 5 | Digit Design: | 7 segments modules are sealed with glue,reach IP67 waterproof grade, with dust shade that make leds work normally all the time. |
| 6 | Brightness: | RED:4000mcd; |
| 7 | Display Dimming: | Over 8 levels of automatic intensity adjustment |
| 8 | Viewing Angle: | Horizontal:60°-120°,Vertical: 60°-120° or customized |
| 9 | Master/slave: | Single sided or double sided, master/slaves available |
| 10 | Led Driving Mode: | Constant current |
| 11 | PC Communication: | RS232/485;LAN(TCP/IP) |
| 12 | Communication Distance: | Max.15 meters for RS232, 1200 meters for RS485 |
| 13 | Remote Control Type: | RF remote control with communication range of 300ft=100M |
| 14 | Other control way options: | GPS, the led sign can work with GPS to adjust the time automatically. |
| 15 | Continuous Working Time: | Unlimited |
| 16 | Lifetime of Leds: | >100,000 hours |
| 17 | Installation Method: | Hanging,mounting or per custom design |
| 18 | Working Temperature: | -30°C~75°C |
| 19 | Display Format: | 88:88:88 |
| 20 | Working temperature | storage:-40~+75°C |
| 21 | Power Input: | 110/220V AC,50-60HZ |
| 22 | Supply Voltage(DC) | 12V |
| 23 | Power(W) | 42W |
| 24 | Power Supply | Chenglian with CE certification |
| 25 | MTBF(Mean Time Between Failure) | >5000 hours |
| 26 | Display lifespan | >100000 hours |
| 27 | Service Access: | Front or rear open |
| 28 | Cabinet Material: | Iron cabinet or aluminum alloy frame |
| 29 | Waterproof Level: | IP53 with aluminum alloy frame, IP65 with iron cabinet |
| 30 | Using environment | Semi-outdoor&Outdoor |
1. Our company:
POOSLED company is a factory that produce LED moving message signs, LED gas price digital
Displays, LED advertisement displays, LED lintel displays and so on.
More importantly, we give our customers the most professional, most satisfactory and in line
With market demand products and the most market competitive capacity of product prices,
So that our distributors can adapt to different periods of market competition.
Our distributors and clients are from all over the world.
2. Our main products:
1)LED Message signs for signle color&Tri color&Fullcolor;
2)LED Gas price signs;
3)LED TIME&TEMP Signs;
4)LED Scoreboards;
5)LED Currency signs;
6)LED Count signs etc...
3. Our main sales history:
1)2008-2009: 1 million US Dollars;
2)2009-2010: 1.3 million US Dollars;
3)2010-2011: 1.5 million US Dollars;
4)2011-2012: 2 milliom US Dollars;
5)2012-2013: 2.3 million US Dollars;
6)2013-2014: 2.8 million US Dollars;
7)2014-2015: 3 million US Dollars.
4. Our LED Exibitions all over China:
1)LED China 2011: Guangzhou, 2011.03
2)LED China 2012: Guangzhou, 2012.03
3)LED LIGHTING FAIR: Zhongshan, 2012.09
4)LED China 2013: Guangzhou, 2013.03
5)LED TECH China 2013: Shenzhen, 2013.09
6)LED Shanghai FAIR 2013: Shanghai, 2013.07
7)LED China 2014: Guangzhou, 2014.03
8)LED TECH China 2013: Shenzhen, 2014.09
9)LED Shanghai FAIR 2014: Shanghai, 2014.07
10)LED SIGN EXPRO 2015: Guangzhou, 2015.03
11)LED DEPES SIGN FAIR 2015: 2015.03
12)LED TECH China 2015: Shenzhen, 2015.09
13)LED China 2015: Shanghai, 2014.03
