| Prod Model: |
bitzer |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
for Refrigerate |
| Place Of Origin: |
Beijing Bitzer |
| Condensation Forms: |
Air-Cooled |
| Type: |
Steam Condenser |
| Certification: |
SGS |
| Condition: |
New |
| Refrigerant: |
R404A |
Product Description
The condensing units are prefabricated, monoblock type, factory tested and easy to mount on the cold room's wall. Built in electronic control panel with microprocessor allows for manual setting of the desired temperature. It has the following features:
1) An on-off button for switching the unit on and off
2) An on-off light button
3) Three temperature setting buttons
4) A manual defrosting button
5) A digital display showing the current room temperature
All condensing units can be equipped with the different types of the refrigerant according to the client's requirements.
| Piston type parallel compressor unit standard configuration |
|
|
| 1.Parallel compressor unit assembly |
| 6. Subcooler assembly (applies for single compressor double stage unit) |
| Sturdy metal chassis |
| Subcooler |
| Lifting ring |
| Subcooling expansion valve, subcooling solenoid valve, subcooling liquid sight glass, subcooling off-valve. |
| Cushion |
|
|
|
| 7. Gas-liquid separator |
| 2.Reservoir assembly |
|
|
| Reservoir has 28 bar safety valve |
| 8. Compressor electronic controller and protection assembly. |
| Reservoir inlet/outlet off-valve |
| Compressor high/low pressure controller. |
| Reservoir sight glass |
| Electronic overcurrent protector. |
| Pipeline liquid sight glass |
| Low pressure sensor |
| Reservoir out filter barrel drier, contains filter |
| Independent circuit breakers and thermal protector. |
| Filter drier barrel oulet has shut-off valve. |
| PLC controller and color touch screen. |
|
|
|
| 3.Exhaust gas assembly |
| 9. Fluid supply manifold and return manifold assembly. |
| Oil separator |
| Fluid supply manifold and return manifold quantity in accordance with product catalog |
| Oil separator outlet backstop shut-off valve |
| Manifold adopts hard straight pipe. |
| |
|
|
| 4. Oil line assembly |
| 10. Other |
| Oil reservoir (with oil sight glass) |
| Compressor pressure gauge |
| Oil reservoir inlet/outlet off valve |
| Repair valves are mounted on each manifold |
| Oil line backstop valve |
| Insulation materials for suction, economizer and cooling tube |
| Oil outlet filter |
| Compressor unit suction off-valve |
| Oil ball valve |
|
|
| Oil level controller |
| 11. Optional configures |
|
| Refrigerant R22 or R404a |
| 5.Single compressor assembly. |
| Reservoir can be vertical or horizontal |
| Suction and discharge off-valve |
| Fluid supply manifold shunt and return manifold shunt |
| Compressor cushion |
| Cooling type: air cooled, water cooled, evaporative cooled. |
| Suction filter barrel, contains filter |
| Other brand compressor and configurations |
| Oil sight glass |
|
|
| Oil pressure controller (oil pump lubrication) |
| 12. Components that can be added |
| Crankcase heater |
| Compressor exhaust muffler |
| Low temperature single stage compressor cylinder fan. |
| High pressure sensor |
| Low temperature single stage compressor liquid spray cooling |
| Heat recovery device. |
|
| Hot gas defrost function |
|
| Frozen oil |
