| Prod Model: |
prepainted steel sheet |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
Alucosuper |
| Thickness: |
0.28-0.8mm |
| Delivery: |
45days |
| Type: |
Steel Plate |
| Technique: |
Hot Rolled |
| Certification: |
RoHS |
| Standard: |
GB |
| Stock: |
Not Stock |
| Surface Treatment: |
Coated |
| Special Use: |
High-strength Steel Plate |
| Application: |
Home Appliance |
Product Description
Brand Name: Alucosuper
Product Name: PPGI / PPGL (PCM)
Thickness of Base Metal: 0.2~0.8mm
Painting material: Polyester(PE) PVDF epoxy
Painting Thickness: 7~30μ M
Surface Protection: PE protective film
Color: Ral code or as the client request
Surface Treatment: Degreasing and chemical treatment
Gloss: 5-105%
Coating Hardness: (pencil resistance) ≥ H
Flexibility: (T-bend) ≤ 2T
MEK: Resistance More than 100
Available size: Width≤ 2000mm, Length≤ 5000mm
Coil: Width≤ 2000mm, N. W≤ 5T, Inner Diameter: φ 408mm φ 505 φ 508
Application:
Home appliance: Refrigerator shutter & side panels, Washer, Freezers, Air conditions, Rice Cooker, Microwave Ovens, Water Heaters, Sterilization Cabinets, Range Hoods Computer Panels, DVD/DVB panels, TV back panel etc.
Teaching Board: Whiteboard, blackboard, greenboard(chalk board).
| Item | Description | Remarks |
| Products name | Color Coated steel coil | Prepainted Coated Metal Vinyl Coated Metal |
| Width | 600mm-1400mm |
|
| Length | as per clients needs |
|
| Thickness | 0.3mm-0.8mm |
|
| Material | DX51D, DX52D, DX53D, DX54D | as per the punch, with shaped pic will be better |
| Surface Coating | PE coating or PET/PVC film | PCM or VCM(composite with PET or PVC film) |
| Color | Ral color no. or any flower style |
|
| Surface Effect | Pure Color, Brushed, kinds of flower style etc. |
| Application | Refrigerator, Wash machine, water heater, freezer, DVD, TV etc. | Shaped in local factory |
| Shipped | Panel | Size is very important |
| MOQ | No need | Test sample / Trial order can be accepted |
| Unit Price | USD/SQM | FOB, CIF, CNF as per your required |
| Package | Pallet | Any special, pls advise |
| Delivery time | 45days | should be confirmed after known all details |
Established in July 2008, Anhui Wonderful-wall Color Coating Aluminium Science Technology Co., Ltd is invested by Zhejiang Wonderful-wall Building Materials Co., Ltd., registered capital of RMB 200 million, with total investment of RMB 430 million. The company is located in Lu'an economic and technological development zone of Anhui province, covering total area of 200, 000 square meters.
Anhui Wonderful-wall Color Coating Aluminium Science Technology Co., Ltd is specialized in the production of color coated aluminium coils, color coated steel coils and solid aluminium sheets. The company has four local and oversea advanced roller-coating and one spray-coating production lines, with the capacity of 60, 000tons/year for color coated aluminium coils, 120, 000tons/year for color coated steel coils, and 700, 000m2/year for solid aluminium sheet. The main products consist of color coated aluminium/steel coils, anti-dirty&self-cleaning aluminium/steel coils, embossed aluminium coils and PVDF spray coated curtain-wall solid aluminium sheet with all shapes. The products are mainly in middle and high position, and have complete specifications: For coated aluminium coils: The thickness is 0.2mm-1.5mm, width is 500-2000mm, For coated steel coils: The thickness is 0.2-0.8mm, width is 500mm-1600mm, For the solid aluminium sheet: The thickness is 2mm, 2.5mm, 3mm. They can widely used in interior and exterior curtain wall decorative panels, aluminium honeycomb panels, suspended ceiling panels, Roofing enclosure materials, household electrical appliances, electronic product, EOE cans materials, shutter, solar energy. etc.
In the management of production technology, Anhui Wonderful-wall Color Coating Aluminium Science Technology Co., Ltd depends on Zhejiang wonderful-wall building materials Co., Ltd. And inherits "Alucosuper" with good reputation and excellent brand. Zhejiang Wonderful-wall building materials Co., Ltd. is specialized in coating aluminium coils, aluminium composite panel and solid aluminium sheet more than twenty years of history. The company is one of the drafters for aluminium composite panel national standard, and is also an establishment member of nation aluminium composite panel association as executive vice chairman of the standing committee ever since. It is the first certification CTC company qualified through the national building materials center, which has a long history and complete production technology.
Anhui Wonderful-wall Color Coating Aluminium Science Technology Co., Ltd is based on Zhejiang wonderful-wall building materials Co., Ltd. And introduce from its mature technology and management system, to ensure good quality bu advanced production equipment. Following the "excellent quality, perfect service, to become the industry leader" of the enterprise purpose, maintain professional essence and pursuit excellent quality, whole-heart to create high-quality modern architecture art space for you
