Guangzhou YunQiang Electronics Co., Ltd. >> Class H 1000W/CH Power PRO Amplifier (K-8010)

Class H 1000W/CH Power PRO Amplifier (K-8010)

Class H 1000W/CH Power PRO Amplifier (K-8010)
Price: US $ 280-300/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: T/T,D/P,Paypal,Money Gram,Western Union
Prod Model: K-8100
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe
Channels: Two Channels
Output: 2
Function: Post Amplifier
Tube Type: Transistor Amplifier
Voltage: AC 220V
Element Number: Push-Pull Amplifier
Output Number: 4
Used For: Professional
Conductive Mode: AB
Usage: KTV System
Sound Channel: 2.1

Product Description

1)Name: 1000W power Pro amplifier for concerts
2)Model: K-8100
3)Application:

1) Arena and stage
2)Convention Centers
3)Medium or large Ballrooms
4)conference rooms
5)Theaters Music
6)Club or Church
7)Concert and music group
4)Pictures and package
Best Stereo AMPS 1000W Power Amplifier
I tem K-8100
Frequency response 20HZ-20KHZ,( + 0, -0. 5 dB )
8ΩStereo Power(RMS) 1 500 W *2
4ΩStereo Power(RMS) 1000W*2
Rated output power 2160W
THD 20 Hz - 20 kHz for 1 W <0. 08 %
Signal-to-Noise Ratio > 96db
Channel   Crosstalk  at  1 kHz >70 d b
Input Connectors (per  CH ) 3-pin XLR, electronically balanced
Output   Connectors (per  CH ) Binding Posts 2-pole
Class TD
Class Protection short circuit,DC voltage,turn-on/off transient,current,inrush
Operating voltage 130-265 V / 65-135 V selectable
Voltage Gain(dB) 23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Fuse 20 A
Level adjustment (per ch.) Front-panel   potentiometer,31 position detente
Dimensions (W×H×D) 48 0W*490D*110H mm
Packing dimension 600*580*190 mm
Net weight(kg) 25KG

Guangzhou YunQiang Electronics Co., Ltd. is a professional audio manufacturer which has R& D, Production department, Marketing Dept., and Technical and service Dept.,

The main products include: Power Amplifier, Karaoke amplifier, Professional Speaker, Karaoke speaker, Sound Mixer, Audio processor and Conferencing systems.

Nowadays, in professional sound industry, more and more people are seeking for amplifiers with light weight, high power output, high sound quality and high stability.

To get good sound quality, we should have high quality components. And to ensure the stability, we must solve the problem of heat dissipation. Now, we have this amplifier FP14000, FP10000Q, FP-8000Q. Our FP14000, FP10000Q, FP-8000Q is Class TD switching amplifier fixed with NOVER (from UK) power capacitors, ON-Semi power transistors other high quality electronic spare parts. Professional circuit design and actual copper heat sink with better structure make fast heat dissipation possible. And fast heat dissipation contributes to high stability of the amplifier. Once you have our amplifiers at your hands, open the chassis, you will find artwork and detail difference. The swich power amplifier can be used to drive line array loudspeaker systems in touring, living show and other applications with high requirement on sound quality and stability.

Since the foundation of our enterprises, we have been concentrating on designing new products, doing research on new sound technology, training our staff, as well as improving our quality to products and management system. And now we have had a unique management experience, advanced production equipment, abundant design capability, and the large marketing network and after-sales service system.

Now we have passed newest CE, FCC, RoHS, SGS, CCC, ISO9001 on March, 2015.

2016 Prolight + Sound Guangzhou

Our booth is A70 4.1.

Address: Area A, China Import & Export Fair Complex. No. 380, Yuejiang Zhong Road, Guangzhou, China.

Time is 29 February~3th, March, 2016
