| Prod Model: |
BDBC-568 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Installation: |
Freestanding |
| Use: |
Freezer |
| Material: |
Steel |
| Style: |
Chest |
| Climate Type: |
St |
| Capacity: |
>501L |
| Door: |
Double |
| Function: |
Cold Storage & Freezing |
| Type: |
Chest/Deep Freezer |
| Door Number: |
Double Doors |
| Defrost Type: |
Manual Defrost |
| Power Source: |
Electricity |
| Temperature Type: |
Double-temperature |
| Temperature Control: |
Mechanical Thermostat |
| Certification: |
CE |
| Door Type: |
Double Open |
Product Description
BD/BC-100A, BD/BC-100, BD/BC-145, BD/BC-200, BD/BC-258, BD/BC-300, BD/BC-388, BD/BC-468, BD/BC-568
Features:
1. Embossed Al board liner is beautiful, durable and excellent in thermal conduction.
2. A food basket is provided together with the machine, fully utilizing space in the box. Partition screen boards are provided to Facilitate the sorted storage of food, saving time and electricity.
3. Thick thermal insulation using advanced foaming technology.
4. Wideband temperature variation design is applied to realize a free selection from the four levels, I. E., cold storage, micro-freezing, freezing and speed freezing. Suitable temperature zone Is selected according to different food.
5. The door seal is in embedded design and can be easily removed and convenient for cleaning.
6. Man-machine engineering principle is applied. A balanced hinge is installed on door-frame, so that the door can be opened from any angle.
7. Fully round corners are in safe design, always taking care of you and your family.
8. The door seal strip is inserted inside the frame opening to reduce coolness loss, which is perfectly energy-saving and environmentally friendly.
9. The thick foaming layer is as thick as 70mm and provides an excellent insulation property.
10. The relatively independent and simple system is a best option substituting small-scale refrigerating house.
11. Lamp inside desgin is optional, and the condenser inside or back-mounted is also optional; (100L, 145L, 200L, 258L, 300L, 388L)
12. The model 200L, 258L, 300L can fix inside sliding glass door.
| Model | BD/BC-100A | BD/BC-100 | BD/BC-145 | BD/BC-200 | BD/BC-258 | BD/BC-300 | BD/BC-388 | BD/BC-468 | BD/BC-568 |
| Capacity | 100 L | 100 L | 145 L | 200 L | 258 L | 300L | 388 L | 468 L | 568 L |
| Climate class | N/T | N/T | N/T | N/T | N/T | N/T | N/T | N/T | N/T |
| Temperature | -18oC to 10oC | -18oC to 10oC | -18oC to 10oC | -18oC to 10oC | -18oC to 10oC | -18oC to 10oC | -18oC to 10oC | -18oC to 10oC | -18oC to 10oC |
| Inside bottom type | Step bottom | Step bottom | Step bottom | Step bottom | Step bottom | Step bottom | Step bottom | Step bottom | Step bottom |
| Power supply | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz |
| Rated input power | 102W | 102W | 102W | 128W |
| 270W | 270 W | 300 W | 300 W |
| Power consumption | 0.86 kwh/24h | 0.86 kwh/24h | 0.95 kwh/24h | 1.20 kwh/24h | kwh/24h | 1.23kwh/24h | 2.20 kwh/24h | 2.50 kwh/24h | 2.50 kwh/24h |
| Refrigerant | R600a/134a | R600a/134a | R600a/134a | R600a/134a | R600a/134a | R134a | R134a | R134a | R134a |
| Net /Gross weight | 31/34 Kg | 31/34 Kg | 36/40 Kg | 40/44 Kg | 44/48 Kg | 50/55 Kg | 67/72 Kg | 72/78 Kg | 79/85 Kg |
| External dimension (mm) | 520× 535× 850 | 621x480x850 | 821× 480× 850 | 831× 610× 850 | 1045*565*850 | 1115× 610× 850 | 1410x642x850 | 1600× 642× 850 | 1885× 642× 850 |
| Packing dimension(mm) | 560x575x870 | 680x570x870 | 880x570x870 | 887x692x870 | 1125x660x870 | 1160x692x870 | 1490x760x870 | 1690x760x870 | 1975x750x920 |
| Loading quantity | 240pcs/40HC | 203pcs/40HC | 156pcs/40HC | 128pcs/40HC | 102 pcs/40HC | 101 pcs/40HC | 70pcs/40HC | 62pcs/40HC | 54pcs/40HC |
Founded in 1994, Zhejiang Jiesheng Refrigeration Technology Co., Ltd. is a manufacturing and export enterprise of refrigeration equipment. Our new factory is located at Leidian Industrial Zone, Deqing County, Zhejiang Province, being only 13km away from Hangzhou.
Our factory' S assets are RMB 15 million, covering an area of around 18, 000 square meters, and our fixed assets are RMB 30 million. We consider "People-oriented, Science-First" as our enterprise spirit. Our company has attracted lots of professional employees, and more than 35 percent of them are technical personnel having intermediate professional titles.
Currently, our factory' S annual production capacity is more than 200, 000 sets of refrigeration equipment, with RMB 120 million of annual sales income. Furthermore, our factory has introduced internationally advanced refrigerating technology and utilized high-quality brand compressors. At present, our company provides domestic markets with commercial refrigerating equipment And low temperature with totally five series and more than seventy models. Besides the domestic market, our products are also distributed to more than twenty countries and regions, such as the USA, England, France, Russia, Australia, India, Chile, Nigeria, Indonesia, Iraq, the UAE, Costa Rica, Nepal, Korea, Vietnam, and Taiwan area etc.
Having stable quality, high efficiency and other features, our products have obtained Chinese and foreign customers' Confidence and praises.
Faced with the rapid development of domestic food and beverage market, our company has developed twenty models of products for supermarkets. Moreover, many Chinese famous enterprises, such as Sanquan, Anjing, Haiyi, Tengxin, Huiyuan, Taizinai, Haibawang, Shenglong, Nengniu, Caoyuanxingfa, Furunjia, Taifeng and Qingdao Beer, are using Jiesheng' S products.
"Concerned about user' S needs, satisfy the demand of market" is Jiesheng' S everlasting aim, we will make great effort to improve our technology and supply quality products and service to satisfy your demands!
Welcome to Jiesheng!
