| Prod Model: |
BD/BC-100 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Installation: |
Freestanding |
| Use: |
Refrigerator |
| Material: |
Steel |
| Style: |
Chest |
| Climate Type: |
ST |
| Capacity: |
60-200L |
| Door: |
Single |
| Power Source: |
Electricity |
| Certification: |
CE |
Product Description
BD/BC-100A, BD/BC-100, BD/BC-145, BD/BC-200, BD/BC-258, BD/BC-300, BD/BC-388, BD/BC-468, BD/BC-568,
Features:
1. Embossed Al board liner is beautiful, durable and excellent in thermal conduction.
2. A food basket is provided together with the machine, fully utilizing space in the box. Partition screen boards are provided to
Facilitate the sorted storage of food, saving time and electricity.
3. Thick thermal insulation using advanced foaming technology.
4. Wideband temperature variation design is applied to realize a free selection from the four levels, I. E., cold storage, micro-freezing, freezing and speed freezing. Suitable temperature zone
Is selected according to different food.
5. The door seal is in embedded design and can be easily removed and convenient for cleaning.
6. Man-machine engineering principle is applied. A balanced hinge is installed on door-frame, so that the door can be opened from any angle.
7. Fully round corners are in safe design, always taking care of you and your family.
8. The door seal strip is inserted inside the frame opening to reduce coolness loss, which is perfectly energy-saving and environmentally friendly.
9. The thick foaming layer is as thick as 70mm and provides an excellent insulation property.
10. The relatively independent and simple system is a best option substituting small-scale refrigerating house.
11. Lamp inside desgin is optional, and the condenser inside or back-mounted is also optional; (100L, 145L, 200L, 258L, 300L, 388L)
12. The model 200L, 258L, 300L can fix inside sliding glass door;
|
Model |
BD/BC-100A |
BD/BC-100 |
BD/BC-145 |
BD/BC-200 |
BD/BC-258 |
BD/BC-300 |
BD/BC-388 |
BD/BC-468 |
BD/BC-568 |
|
Capacity |
100 L |
100 L |
145 L |
200 L |
258 L |
300L |
388 L |
468 L |
568 L |
|
Climate class |
N/T |
N/T |
N/T |
N/T |
N/T |
N/T |
N/T |
N/T |
N/T |
|
Temperature |
-18oC to 10oC |
-18oC to 10oC |
-18oC to 10oC |
-18oC to 10oC |
-18oC to 10oC |
-18oC to 10oC |
-18oC to 10oC |
-18oC to 10oC |
-18oC to 10oC |
|
Inside bottom type |
Step bottom |
Step bottom |
Step bottom |
Step bottom |
Step bottom |
Step bottom |
Step bottom |
Step bottom |
Step bottom |
|
Power supply |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
|
Rated input power |
102W |
102W |
102W |
128W |
|
270W |
270 W |
300 W |
300 W |
|
Power consumption |
0.86 kwh/24h |
0.86 kwh/24h |
0.95 kwh/24h |
1.20 kwh/24h |
kwh/24h |
1.23kwh/24h |
2.20 kwh/24h |
2.50 kwh/24h |
2.50 kwh/24h |
|
Refrigerant |
R600a/134a |
R600a/134a |
R600a/134a |
R600a/134a |
R600a/134a |
R134a |
R134a |
R134a |
R134a |
|
Net /Gross weight |
31/34 Kg |
31/34 Kg |
36/40 Kg |
40/44 Kg |
44/48 Kg |
50/55 Kg |
67/72 Kg |
72/78 Kg |
79/85 Kg |
|
External dimension (mm) |
520× 535× 850 |
621x480x850 |
821× 480× 850 |
831× 610× 850 |
1045*565*850 |
1115× 610× 850 |
1410x642x850 |
1600× 642× 850 |
1885× 642× 850 |
|
Packing dimension(mm) |
560x575x870 |
680x570x870 |
880x570x870 |
887x692x870 |
1125x660x870 |
1160x692x870 |
1490x760x870 |
1690x760x870 |
1975x750x920 |
|
Loading quantity |
240pcs/40HC |
203pcs/40HC |
156pcs/40HC |
128pcs/40HC |
102 pcs/40HC |
101 pcs/40HC |
70pcs/40HC |
62pcs/40HC |
54pcs/40HC |
