Product Description
Item name: MFCR001
Power Requirements +12V DC
Weight: 250 g
Frequency 13.56MHz Proximity Mifare Card
Reading the serial number of Mifare and compatible card
Read Indication LED and Beeper
Temperature: -15Degree and +55Degree
Dimensions: 120mm*80mm
Output: WG26, SY485, RS485, RS232 and ABA.
Reading range: 5-8cm
Item name: MFCR002
Power Requirements +12V DC
Weight: 150 g
Frequency 13.56MHz Proximity Mifare Card
Reading the serial number of Mifare and compatible card
Read Indication LED and Beeper
Temperature: -15Degree and +55Degree
Dimensions: 100mm*40mm
Output: WG26LX, SY485LX, RS485LX, RS232LX and ABA.
Reading range: 3-5cm
Item name: MFCR003
Power Requirements +12V DC
3x4 keypad available Weight: 250 g
Frequency 13.56MHz Proximity Mifare Card
Read Indication LED and Beeper
Temperature: -15Degree and +55Degree
Dimensions: 120mm*80mm
Output: Standard WG26 Reading range: 5cm
Application: Access control, Attendance control, Identification
Item name: MFPS2
Keyboard emulation without external power.
Weight: 150 g
Frequency 13.56MHz Proximity Mifare Card
Reading the serial number of Mifare1 compatible IC Card
Read Indication LED and Beeper
Temperature: -15Degree and +55Degree
Dimensions: 100mm*40mm Reading range: 5cm
Application: Access control, Attendance control, Identification.
Item name: MFRW01
Without external power. Weight: 200 g
Frequency 13.56MHz Proximity Mifare Card
Read and write ISO 14443A card, Mifare s50, Mifare s70, Ultralight.
Indication LED and Beeper
Temperature: -15Degree and +55Degree
Dimensions: 110mm*80mm
Output: USB, , RS232 demo software, dll & STK available with C/VB/DP/PB
Reading range: 5-10cm
Application: Access control, Attendance control, Identification.
Item name: MFRW02
Without external power.
Weight: 200 g
Frequency 13.56MHz Proximity Mifare Card
Read and write, Mifare s50, Mifare s70, Ultralight.
Indication LED and Beeper
Temperature: -15Degree and +55Degree
Dimensions: 143mm*140mm*28mm
Output: USB, , RS232 demo software, dll & STK available with C/VB/DP/PB
Reading range: 5-10cm
Application: Access control, Attendance control, Identification.
Item name: RW14443B
Without external power
Frequency 13.56MHz ISO14443 Type B Card, as AT88RF020\SR176\SRIX4K\TRH1064^
RS232 demo software, dll & STK available with C/VB/DP/PB
Indication LED and Beeper
Temperature: -10Degree and +50Degree
Dimensions: 110x80mm
Weight: 200g Reading range: 5-10cm
Application: Access control, Attendance control, Identification.
Iterm: RW15693
Without external power
Frequency 13.56MHz ISO15693 Ti Tag-it, Ti-2048bit, Philips I-code2 ^
RS232 demo software, dll & STK available with C/VB/DP/PB
Indication LED and Beeper
Temperature: -10Degree and +50Degree
Dimensions: 110x80mm
Weight 200g.
Item name: CF RFID Reader and Writer
Consumption: 5mA 3.3V
Link port: CF
Frequency: 13.56MHz, ISO14443A, ISO/IEC14443B,
ISO/IEC15693
Read and write Mifare card, Desfire, I code SLI, SR176 etc.
Temperature: -10Degree and +50Degree
Dimension: 430mm*60mm*75mm Weight; 500g
Indication LED and Beeper
Reading range: 6cm with 14443A/B card/tag, , 7cm with 15693 card/tag
Item name: SDIO RFID Reader and Writer
Consumption: 5mA 3.3V Link port: SD
Frequency: 13.56MHz, ISO14443A, ISO/IEC14443B,
ISO/IEC15693
Read and write Mifare card, Desfire, I code SLI, SR176 etc.
Temperature: -10Degree and +50Degree
Dimension: 24mm*53mm*8mm Weight; 20g
Indication LED and Beeper
Reading range: 6cm with 14443A/B card/tag, 7cm with 15693 card/tag
Application: Access control, Attendance control, Identification.
TEFECT is one of the biggest domestic manufacturers in contact card, RFID and RFIC series products including card, special size card, key tag, label, card reader and writer, and terminals (More details check our catalogue). Our factory boasts a production base covering a land area of 2500 square meters, 250 staffs, and more than 20 technicians, with yearly output 20, 000, 000PCS of standard cards, special size card and more than 100, 000PCS readers. During passed more than 15years, we devoted ourselves to the Hi-tech development and intelligent products. Through these years' endeavor, now we have formed an aggregation in studying, manufacturing, marketing, and after services.
Cards products include various available chips covering 125KHz, 13.56MHz and 915MHz( ISO 14443, ISO15693, ISO18000 and ISO EPC), no battery, such as EM4100, EM4102, TK4100, Temic5557, Mifare1kS50, Mifare4KS70, Ultralight, Hitag1, Hitag2, HitagS, I-code1, I-codeSLI, SLE66R35, SHC1104, FM11RF08, SR176, ATMEL 88RF020, Ti2048, Ti256, Legic256, Inside 2k\16K, U-code HSL, U-code EPC, GEN2, XRA00.
Reader products include reading and writing module, readers, writers, long-range readers which ranges from 125 KHz, 13.56 MHz to915 MHz, with various output Port such as RS232, RS485, USB, TCP-IP, PS2, WG26, WG34, WG42, ABA, ABA2.
We would like to cooperate with every old and potential client hand in hand and create a wonderful and bright tomorrow jointly.
