| Prod Model: |
SP1001128 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
DVD Player |
| Color: |
Black |
| Type: |
Coaxial |
| Certification: |
CCS |
| Connector: |
RCA |
| Brand: |
Jyft |
| Wire Core Material: |
CCS |
Product Description
AUDIO/VIDEO cable (SP1001128)
ConductorSize
Construction10/0.10ACP±0.008mm
Conductor MaterialCCS
InsulationThickness0.36mmREF
Diamerial1.1±0.05mm
Colorred,white,yellow
Material35P PVC
ShieldedFillet ShieldN/A
Spiral Shield MaterialCCS
Spiral Shield Constructions10±2PCS/0.10ACP
Spiral Shield Coverage35%
Drain MaterialN/A
Drain ConstructionN/A
AL/MylarN/A
JacketThickness0.71mmREF
ColorBlack
MaterialPVC 55Pa
DiameterΦ2.5*7.5mm±0.15mm
|
Model |
Name |
Unit |
Spec |
Metal Plug Spec |
Diameter |
Colour |
|
SP1001128 |
AUDIO/VIDEO cable |
PIC |
1F 2M/1M 2F |
|
5MM |
|
