Prod Model: |
LLT-PR3115 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Navigation Host Size: |
148*118*40(Mm) |
Gr. Wt: |
0.75kg |
CPU: |
1.2ghez/1.6GHz |
RAM: |
1GB Ddriii |
Flash: |
8GB Nand Flash |
U Flash Disk: |
8GB |
Antenna Current: |
27db |
Maximum Height Positioning: |
18, 000m |
Tracking Sensibility: |
-159dBm |
Certification: |
ISO |
Video Output: |
VGA |
Audio Output: |
Digital Optical Output |
Voltage: |
12/24V |
Placement: |
Dashboard |
Combination: |
Reversing Track |
Product Description
HD Android Navigation Box With High Definition for Kenwood Module
HD/800*480 Android Box, Android Navigator,Android Unit/Android unit system,GPS Android Box installed Original car Unit for Pioneer/Sony/JVC with
AVH 1650, 2650, 4650, 5650, 8650,AV61, AV71, V10, V20, V40,DDX630, DDX630BT,Toyota Prius 10-30
The Best
Super-strong Dual-core processor: Cortex A8 1.2GHz
The Strongest compatibility: Match up with different screen and display affection
Maximum Video formats: AVI (H. 264, DIVX, DIVX, XVID, rm, rmvb, MKV (H. 264, DIVX, DIVX, XVID), WMV, MOV, MP4 (H. 264, MPEG, DIVX, XVID), MPEG, MPG, FLV (H. 263, H. 264)
Support maximum 32G external U Flash Disk and Hard Disk
Support Maximum 32G external TF/SD card
Operating system: Android 4.2/4.4 more stable!
Support varieties of resolution, Maximum 800*480
Support TMC (TRAFFIC MESSAGE CHANNEL)
External E-dog with Full frequency radar LDT
Support touch screen control, and share a touch screen
Reset the factory settings
Wi-Fi Hotspot Tethering, Wi-Fi wireless Internet and 3G Internet
USB 2.0 OTG HOST port which can connect computer and storage space can connect this machine. Vast of Audio format: WAVE, AIFF, AU, MP3, MIDI, WMA,
RealAudio, VQF, OggVorbis, AAC, APE; Support AVIN
SYSTEM PARAMETER |
Frequency | 1.2G~1.5G Hz |
Chip | A20 |
RAM | 1GB DDRIII |
Storage space | 8GB NAND Flash |
Navigation software storage | SD/TF card |
Operating system | Android 4.2/4.4 |
Multimedia and Performance |
Audio | WAVE\AIFF\AU\MP3\MIDI\WMA\RealAudio\VQF\OggVorbis\AAC\APE |
Video | AVI(H.264, DIVX, DIVX, XVID, rm, rmvb, MKV(H.264, DIVX, DIVX, XVID), WMV, MOV, MP4(H.264, MPEG, DIVX, XVID), MPEG, MPG, FLV(H.263,H.264) |
Audio interface performance | 1080P HD Video playback |
Image browser |
Map Type | BMP/JPG/GIF/PNG |
Text-based browser |
Text Type | TXT |
Internet |
Network Type | EVDO/W-CDMA/Wi-Fi |
Network speed | 7.2M/S |
GPS Hard Software |
CS | SIRF IIIOR U-BLOX 6 |
Frequency | 1.575GHZ |
C/A CODE | 1.023 MHZ chip rate |
Port numbers | 20 |
Tracking sensibility | -159dBm |
Positional accuracy | 10m, 2D RMS |
5m, 2D RMS, WAAS enable |
Rate | 0.1m/s |
Date updating rate | 1HZ |
Capture time | Average 0.1s(OPEN SKY) |
Hot boot time | Average 3s(OPEN SKY) |
Warm boot time | Average 38s(OPEN SKY) |
Clod boot time | Average 45s(OPEN SKY) |
Maximum height positioning | 18,000m |
Maximum rate | 515m/s |
Acceleration | < 4g |
External antenna interface | SMA |
External antenna voltage | 3.3V±5% |
External antenna gain | 27dB |
External antenna current | 15mA |
USB Parameter and Performance |
USB interface Type | USB 2.0(High Speed)Device |
USB Performance | Connect PC, Support U Flash Disk |
