| Prod Model: |
POS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Housing Material: |
Aluminum Alloy |
| Touch Panel: |
Mapletouch Resistive Touch |
| Expand Function: |
Built in WiFi |
| Color: |
Black, White |
| Certification: |
FCC |
| Printer: |
Thermal |
| Touch Screen: |
Touch Screen |
| System: |
Windows |
| Type: |
Hand Held |
| CPU: |
Intel |
Product Description
CPU(GHz)1.86G
Core LogicIntel Atom D2550
System Memory (DDRIII)2G, or 4G
OS SupportWin XP, Win Vista, Win 7, WEPOS, Linux
Display
TFT LCD15"
Brightness250 CD/
Resolution1024X768
Touch Screenmapletouch 5wire resistive
Tiliting Angle(degree)15-90
Storage Device
HDD(GB) 2.5" SSD 32G, optional 320G, SSD 16G
I/O Ports
Serial(RS232)2 X RS-232 (Maximum extension 6*RS232)
USB4 USB-2.0
PS/21
LAN1*Realtek RTL8111DL 100/1000Mbps, can optional two LAN interface
VGA1*dB-15
Cash Drawer(RJ11)yes
LPT1*dB-25
AudioRealtek ALC892 Audio
Wirelee LAN optional
Expansion1*PCIex1, 1*Mini PCI-E Expansion slots
Others
ColorBlack, Silver
CertificationsCE, FCC, CCC, RoHS, CB
Weight (Kg)8
Optional Accessories
2ND DisplayYes
Customer DisplayVFD2X20, Cost extra $52
MSRTrack1+2+3 Cost extra $45
I ButtoniButton / Dallas Key Reader, KB I/F, I Key N/A
Wall Mount BracketYes, (option) VESA 75 mm
|
CPU(GHz) |
1.86G |
|
Core Logic |
Intel Atom D2550 |
|
System Memory (DDRIII) |
2G ,or 4G |
|
OS Support |
Win XP, Win Vista, Win 7, WEPOS, Linux |
|
Display |
|
|
TFT LCD |
15" |
|
Brightness |
250 cd/ |
|
Resolution |
1024x768 |
|
Touch Screen |
mapletouch 5wire resistive |
|
Tiliting Angle(degree) |
15-90 |
|
Storage Device |
|
|
HDD(GB) |
2.5" SSD 32G,optional 320G,SSD 16G |
|
I/O Ports |
|
|
Serial(RS232) |
2 x RS-232 (Maximum extension 6*RS232) |
|
USB |
4 USB-2.0 |
|
PS/2 |
1 |
|
LAN |
1*Realtek RTL8111DL 100/1000Mbps ,can optional two LAN interface |
|
VGA |
1*DB-15 |
|
Cash Drawer(RJ11) |
yes |
|
LPT |
1*DB-25 |
|
Audio |
Realtek ALC892 Audio |
|
Wirelee LAN |
optional |
|
Expansion |
1*PCIex1 ,1*Mini PCI-E Expansion slots |
|
Others |
|
|
Color |
Black , Silver |
|
Certifications |
CE, FCC, CCC, RoHS,CB |
|
Weight (Kg) |
8 |
|
|
|
|
Optional Accessories |
|
|
2nd Display |
Yes |
|
Customer Display |
VFD2X20, Cost extra $52 |
|
MSR |
Track1+2+3 Cost extra $45 |
|
I Button |
iButton / Dallas Key Reader, KB I/F,i – Key N/A |
|
Wall Mount Bracket |
Yes, (option) VESA 75 mm |
Guangzhou yulian electronic technology Co., Ltd. is the mainly professional manufacturer in producing mapletouch POS terminals, industrial control systems and multifunction inquiry touch kiosks in China. We have been an innovative and creative force in the development and manufacturing of high quality, high performance systems since 2000. Now our products have obtained the certificates of ISO9001: 2000, CE, FCC, CCC, CB, ROSH and widely applied to many fields.
