| Prod Model: |
KF120-A/320 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Heat Source: |
Air-source + Water-source |
| Certification: |
CE |
Product Description
Sole hot water facilities supplier for Olympic Village in Beijing
New Times air source heat pump (with water tank) unique:
1) Japanese Panasonic Compressor;
2) Evaporator is larger than usual size to keep its high efficiency
3) Water pressure reaches 0.6Mpa-0.9Mpa;
4) Refrigerant R407c:- ODP = 0, GWP=1610
5) Excellent 304# stainless steel pressurized water tank;
6) Full automatically start up and stop with setup temperature;
7) 36 patents with self-developed
8) Normal operation in estra-low temperature of -15~20ºC with COP1.5~2
9) LCD tourch-screen controller
10) Small space and easy install&maintain.
Model
|
|
XSD-1.5H-C
|
KF120-A/320
|
Rated heating capacity
|
kw
|
5.58
|
|
Btu
|
19000
|
COP
|
|
4.46
|
Rated water flow rate
|
L/h
|
120~150
|
Rated outlet temperature
|
º C
|
55
|
Max outlet water temp
|
º C
|
60
|
Rated input power
|
kw
|
1.25
|
Power supply
|
V~Hz
|
220V~50Hz
|
Heat pump Dimmesion
|
mm
|
850*320*540
|
Water tank Dimmesion
|
mm
|
¢ 560*1750
|
Pressured water tank capacity
|
L
|
320
|
COP& Ambient temperature
|
º C
|
2.5~6 & (- 12 º C~ + 43 º C)
|
Compressor type
|
|
Rotary
|
Testing Condition:
Outside temperature is 20 º C/ 15 º C. Input water temperature is 15 º C, output is 55 º C.
|
Established in 1994, Dongguan New Times New Energy Science & Technology Co., Ltd. is one of the famous enterprises specializing in manufacturing air source heat pump water heater in Guangdong Province, China. With more than 20, 000 square meters manufacturing factory and 15 years of technology experiences of R&D, we have owned independent intellectual property right and more than 30 patented technologies.
Our main product lines, with annual output of 30, 000 sets, include household and commercial air to water heat pump, integration of heating and cooling module unit, swimming pool air source heat pump, and high-temperature air source heat pump(up to 80ºC) as well. They can provide hot water from 45ºC to 80ºC, and also for heating in winter, cooling in summer. Our products have heating and cooling capacities ranging from 9, 000 to 1000, 000BTU.
The annual output value reaches over RMB200 million. All of our products are of high quality, good appearance, durable, and well performance in low temperature environment. We used advanced production equipment and testing machines, such as America Copland Compressor, Japan Panasonic Compressor, America high efficiency shell and tube heat exchanger, Freon inspectors, and electrical safety testing equipment. What's more, we are certified by 3C, CE, ISO9001: 2000 (UKAS) and ISO14001.
Our main markets include Europe, America, the Middle East, Southeast Asia, South Africa and Australia. With a highly effective management team, modern facilities, and excellent pricing, we endeavor to offer high quality products and the latest technology for incredible success and growth. We look forward to expanding our customer base and invite you to contact us for more products and company information.
