| Prod Model: |
EL0070MC107 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
LCM |
| Usage: |
Small-sized LCM |
| Touch Screen Type: |
Capacitive |
| LCD Drive Mode: |
Static Drive LCD Module |
| DOT-Matrix Graphic LCD Module Type: |
Row/Column-Driven Control Type |
| Digital LCD Module Type: |
Counting Module |
| Display Technology: |
TFT |
| Viewing Angle: |
TN＋FILM |
Product Description
| 7.0 " TFT LCD Module Functions & Features |
| Part NO. |
EL0070MC107 |
- |
| Parameter | Value | Unit |
| LCD Mode | TFT/Transmissive | - |
Pin Descriptions |
50 |
- |
Display color |
16M |
dots |
| Dimensional outline |
164.9(H)*100.2(V)*3.5(T)MM (FPC not include) |
mm |
Active Area |
153.84 x 85.63(W×H) |
mm |
| Power Supply Voltage |
3.3 |
V |
| Viewing Direction | 6 o'clock | - |
| Display Mode | Normally white | - |
Data Transfer |
RGB |
- |
| Back-light |
15-LEDs (white) |
pcs |
| Operating temp.: | -20ºC~ +70ºC | - |
| Storage temp.: | -30ºC~ +80ºC |
Company Strength:
.............................................................................................................................................................................
1> High quality & Competitive price
2> RoHS Compliant.
3> In stock, samples lead-time: 1 --3 days
4> Short lead-time& Factory supplied
5> One year warranty and best after sales service
6> Small MOQ
We, Shenzhen Elida Technology Co., Ltd., are a high-tech company focused on liquid crystal display and electronic touch screens.
With the first-class automatic production line and the specialized management and R&D team, our company is supplying Monochrome graphics and character LCD modules in TN, STN and FSTN technologies and TFT LCD Module products.
Elida technology strives to deliver customized services with best quality, and every product undergoes multiple QC stages to ensure optimum performance and functionality and is CE certified as well as RoHS compliant.
We sincerely welcome your proposal and cooperation! Please feel free to contact us for any of your LCD / LCM projects and requirements.
