65'' All in One PC Touch Screen for Wall

Prod Model:	PM650TAIO(for wall)
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Diagonal Size:	65"
Pixel Pitch:	0.744(H) X 0.744(W)
Response Time:	5.5ms
Resolution:	1920X1080
Contrast Ratio:	5000:1
Activve Display Area:	1428.48(H)X803.52(V)
Brightness:	500d/M2
Display Color:	16.7m
Viewing Angle:	H:178 Degree V: 178 Degree
Warranty:	13 Year
Screen Size:	>60 Inches
Aspect Ratio:	16:9
Customized:	Customized
Screen Type:	Infrared

Product Description

[Description]
65'' All In One pc Touch Screen For Wall
TAIO's full name is Touch all in one. This product include touch screen and PC system inside. Interactive touch screen, is integrated with multimedia equipment and display the touch screen module, liquid crystal display LCD technology is set, the technology of electronic whiteboard solution for the integration of high-tech products.

[Function]
The configuration is follow customer require. Such as CPU, Memory, Hdd and so on.
Support windows XP/7/8.
Interactive touch function, combined with the special software, can achieve interactive effect.
Multitouch support in windows7/8, support 2 ~ 32 points multi-touch function.
Free correction, free driving function, easy for user without driver.
FHD LED screen, high brightness, and high contrast, high resolution.
Compatible USB playback function, including video, pictures, MP3 players and other various playback mode.
Multimedia function, this product have various interface: HDMI, USB, etc., compatible and easily connect a variety of peripheral devices.
The speed of touch up to 300 points, writing smooth, fast response.
Support single point touch, the mouse control, multi-touch, available to different situation.
Can be used with a variety of software, to adapt to a variety of applications.

PC system
CPU	Intel 1037U (I3,I5,I7 option)
Chipset	Intel chipset
Graghpic Chipset	Integrated graphics
Memory	2G(4G/8G/16G option)
Hardisk	500G(Option: SSD)
Lan	10M/100M
WIFI	Option
Audio
Stero Speaker	2x10W
PC system I/O
USB 3.0	X2
USB 2.0	X2
Lan(RJ45)	X1
Audo Output	X1
Mic	X1
DisplayPort output	X1
HDMI output	X1
RS232 port	Option
VGA output	Option
Touch parameters
Inductive technology	Infrared Single/Double touch
Touch point	1~32 points
Inductive objects	Finger,pen, any other non-transparent objects
Inductive size	Diameter≥5mm,recommended size≥7mm
Resolution	4096*4096
Response time	Dual touch:first click:8ms,continuous:8ms
	Single touch: first click: 8ms,cintinuous:3ms
Cursor speed	Single: highest 300 dot/s, dual touch:125 dots/s
Operating life	≥60,000,000 times to touch
Multi Touch	Support Wind7/8
Positioning calibration	Support HID device, plug and play, no need driver and calibration, match-management program for positioning calibration.
Light anti-decay	light anti-decay circuit, maitains stable performance for a long-time working
Anti-light interference	Can work in the condition of direct sunlight
Technical Specification
OSD language	Simplify Chinese, English
Horizontal Frequency	20 ~ 82KHz(Anolog&Digital)
Vertical Frequency	55~75Hz
Optimum Resolution	1920x1080 at 60HZ
Native Resolution	1920x1080 at 60HZ
Supported Resolutions	1920x1080;1680x1050;
	1440x1050;1360x768;
	1280x1024;1280x768;
	1024x768; 800x600;
	720x400; 600x480;
Video Modes(no tuner)	480i;480p;576i;576p;
	720p(50 / 60HZ);
	1080i(50 / 60HZ);
	1080p(50 / 60HZ);
Operation/Sotrage
Operating Temperature	00C~400C
Operating Humidity	10%~90%
Storage Temperature	-200C~600C
Storage Humidity	0%~90%
