| Prod Model: |
HPA600-Q |
| Refrigerature: |
R134A/R22 |
| Rated Voltage(V): |
AC220V/DC48V/50Hz/60Hz |
| Rated Refrigerating(W): |
600W |
| Noise Level(dB): |
59 |
| Weight(Kg): |
25 |
| Color: |
Ral 9002 |
| Keywords: |
Industrial Air Conditioner |
| Type: |
Cabinet Air Conditioner |
| Operating Voltage: |
230 VAC |
| Certification: |
CCC |
| Condition: |
New |
| Application Fields: |
Telecom Cabinet, Machine Cabinet,Wine Cellar |
| Mounting: |
Cabinet Door |
Product Description
600w Industrial Airconditioner/ Cabinet Air Conditioner
---------------------------------------------------Product pictures ---------------------------------------------------------
----------------------------------------------Technical Specifications------------------------------------------------
| Item | HPA300-Q | HPA600-Q | HPA1000-Q | HPA1500-Q | HPA2000-Q |
| Cooling Capacity(W) | 300 | 600 | 1000 | 1500 | 2000 |
| operating voltage | 220V~50HZ |
Noise
dB(A) | 63 | 63 | 63 | 63 | 63 |
| Working Temperature Ranger | -40ºC~55ºC |
| H(mm) | 500 | 750 | 1100 | 1100 | 1100 |
| W(mm) | 300 | 430 | 430 | 430 | 430 |
| D(mm) | 156 | 195 | 195 | 195 | 240 |
| Refrigerant | R134a |
| Inner IP | IP55 |
| L25- L35(ERR) | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 |
| L25- L43(ERR) | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 |
Rated Power(W)
L25-L35 | 188 | 375 | 625 | 975 | 1250 |
-----------------------------------------Features-------------------------------------------
1. Energy Conservation and Environment Protection
1.1 International brand's high energy efficiency compressor
1.2 International brand's low-power centrifugal fan
1.3 Environmentally friendly CFC-free refrigerant R134a.
1.4 High energy efficiency ratio (EER) design
1.5 High volume of wind, small enthalpy variance, high sensible heat ratio design
------------------------------Application Area------------------------------------------
1. Equipment cabin of Mini ICT room
2. Equipment cabin of RRU outdoor cabinet
3. Equipment cabin of 4G base station outdoor cabinet
4..Equipment cabin of micro station outdoor cabinet
5. Electric power outdoor cabinet
6. Industrial control cabinet refrigerating
7. Laboratory dedicated refrigerating
8. Museum, wine cellar dedicated refrigeration
9. High luminance LCD/LED dedicated refrigerating
--------------------------------------Certification-----------------------------------------
CE, ISO9001, ISO14001
------------------------------------------------Cooperation member----------------------------------------------------
-
--------------------------------------------------Installation Drawing-----------------------------------------------------
The video link of cabinet air conditioner installation:
http://www.tudou.com/programs/view/-W2OY85dKDQ/
---------------------------------------Packing terms--------------------------------------
Using high quality waterproof to pack the air conditioner first, then using melaleuca kraft packing, final using thick laminates.
----------------------------------------Leading time--------------------------------------
Usually about 20 days. The exact lead time need to be confirmed according to the quantity of order.
--------------------------------------Shipment--------------------------------------
Pointed delivery-agent. DHL,UPS or Fedex by your account will be all ok. Also we can hunt for the delivery agent with the best price in China if you need us to do for you.
---------------------------------Situational Application---------------------------------
For more info.or customized industrial cooling solutions,please contact us anytime.
Chengdu Hop Environmental Protection Technology Co., Ltd. Are specialized Research and development in Indurstrail air conditioning and electric energy meter more than 20 years, We are committed to environmental protection and energy conservation, hope that through our efforts to bring better environmentally friendly products for the world.
We also are supplier of China telecom China moble and China Unicom.
With over 10 years' manufacturing & trading experiences, our products have got dozens of patent-letter, and are hot sale all over the world since 2004.
Our continuous innovation based on customer needs, has established our leading position in energy-saving equipment, industrial air conditioning, energy management and environment monitoring.
We take "professional, careful, thorough" for the idea. Strive to do the "low-carbon life, low-carbon development, fine energy-saving"!
