| Prod Model: |
FP10000Q |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand: |
TDS |
| Product Type: |
Switch Model Power Amplifier |
| Output Power: |
4CH X 1300 Watts |
| Place Of Orignal: |
Guangzhou China |
| Used For: |
Professional |
| Tube Type: |
Transistor Amplifier |
| Function: |
Amplifier Combined |
| Output Number: |
4 |
| Voltage: |
AC 220V |
| Element Number: |
Push-Pull Amplifier |
| Conductive Mode: |
AB |
| Usage: |
Professional Performance |
| Sound Channel: |
4CH |
Product Description
Power Amplifier (FP10000Q)
Features
1. 4CH switch model power amplifier.
2. Branded Motorola transistor.
3. Lightweight but working powerful.
4. Heat sink part with pure copper material.
5. 4 years products warranty.
High performance power amplifier. Stable performance amplifier. PRO amplifier. Amplifier for line array system. Good quality switching modul power amplifier
| Specification |
|
| Model | FP10000Q |
| 8ohm Stereo Power (RMS) | 4 x 1300 watts. |
| 4ohm Stereo Power (RMS) | 4 x 2200 watts. |
| 2ohm Stereo Power (RMS) | 4 x 2400 watts. |
| 8ohm Bridge Power (RMS) | 2 x 4400 watts. |
| 4ohm Bridge Power (RMS) | 2 x 4800 watts. |
| Frequency Response | 10Hz -- 30KHz +/-3dB. |
| THD | < 0.1% |
| S/N Ratio(dB) | 110dB |
| Voltage Gain | 23,26,29,32,36,38,41,44dB |
| Input Connector | 3 pins. XLR |
| Input Impadance | 20K ohm Balance / 10K ohm Imbalance |
| Output Connector | Speakeon & conntact pins. |
| Operating Voltage | 200V - 240V / 50-60Hz. |
| Dimension (W x H X D) | 483 x 88 x 377 |
| Net Weight (kg) | 13 kg |
| Gross Weight (kg) | 15.5 kg |
