| Prod Model: |
HL-CTS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Screen Size: |
40-50 Inches |
| Aspect Ratio: |
16:9 |
| Application: |
Public Information Inquiry System |
| Screen Type: |
Capacitive |
| Resistive Touch Screen Type: |
Digital |
| Customized: |
Customized |
Product Description
| Control Board Electrical Characteristics |
| Interface | Standard Full Speed USB;USB2.0 and above compliant |
| Power Supply | +5Vdc <500mA(via USB connection) |
| Device Driver | Windows:Win8 Retail Version,Win7,XP* |
| IOS*:Mac OS(Mavericks) |
| Android:5.0,4.0 - 4.4 |
| *Limited to single-points touch |
| Dimensions(mm) | 280*60 |
| Operating Temperature | Industrial Temperature Grade (-40ºC to +85ºC) |
| Regulatory and Environmental |
| Electrostatic Discharge Immunity(ESD) | Air Discharge:±8kv ; Direct Contact Discharge:±4kv |
| Electromagnetic Interference Immunity(EMI) | FCC CFR Part 15 Subpart B&C
EN55022(CISPR 22)classB |
| Control Board Performance |
| Parameter | Description | Min. | Typ. | Max. |
| Number of Multi-Touch Points | Maximum number of simultaneous touch points supported | - | 10 | 32 |
| Scan Rate (Hz) | Rate to scan and measure change in capacitance on sensor | - | 120 | - |
| Wake-Up Response Time (ms) | Wake-up time between first finger-touch event and controller
reporting | - | 25 | - |
| Single-Touch Accuracy (mm) | Position error between actual and reported finger position | - | ±1.5 | - |
| Multi-Touch Accuracy (mm) | Position error between actual and reported finger position | - | ±1.5 | - |
| Single-Touch Linearity (mm) | Deviation in measurement of a straight line touch | - | ±1.5 | - |
| Multi-Touch Linearity (mm) | Deviation in measurement of a straight line touch | - | ±1.5 | - |
| Finger Separation (mm) | Edge-to-edge distance for distinguishing two points | - | 10 | - |
| Passive Stylus Support (mm) | Size of passive stylus that can be supported | 5 | 9 | - |
| Palm Rejection | Details of palm rejection capabilities | 30x30mm Large Area Rejection |
Product Specification Sheet
Application: Public Information Inquiry System
Screen Type: Capacitive
HUILI TECHNOLOGY CO.,LTD
HUILI TECHNOLOGY Co., Ltd(HUILI TECH for short)is a creator and supplier of IR Multitouch Overlay and Kiosk. We concentrated development and promotion on interaction application technology. We have got CE, FCC, IP65 and RoHS certificates.
HUILI TECH is a comprehensive high-tech enterprise which is integrated with manufacturing, sale and service. We provide 15"~98" IR Multitouch Overlay, super size multi-touch splicing wall and kiosk.
HUILI TECH gives media companies, advertisers, event and exhibition organizers the ability to display digital contents in various public locations, including museums, science centers, amusement parks, tradeshows, retail locations, bars & nightclubs, real estate presentation centers, corporate showrooms, boardrooms and airports.
Welcome new and old customers from all walks of life to contact us for future busniess relationships and mutual success!
