| Prod Model: |
PM420TAIO |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Diagonal Size: |
42" |
| Aspect Ratio: |
16:9 |
| Pixel Pitch: |
0.4845(H) X 0.4845(W) |
| Response Time: |
<5ms |
| Resolution: |
1920X1080 |
| Contrast Ratio: |
1300:1 |
| Brightness: |
450CD/M2 |
| Activve Display Area: |
930.24 (H) X 523.26(V) |
| Display Color: |
16.7m |
| Viewing Angle: |
H:178 Degree V: 178 Degree |
| Screen Type: |
Infrared |
Product Description
[Description]
42" Inch Touch Screen monitor TV All in One
TAIO's full name is Touch all in one. This product include touch screen and PC system inside. Interactive touch screen, is integrated with multimedia equipment and display the touch screen module, liquid crystal display LCD technology is set, the technology of electronic whiteboard solution for the integration of high-tech products.
[Function]
The configuration is follow customer require. Such as CPU,Memory,Hdd and so on.
Support windows XP/7/8.
Interactive touch function, combined with the special software, can achieve interactive effect.
Multitouch support in windows7/8,support 2 ~ 32 points multi-touch function.
Free correction, free driving function, easy for user without driver.
FHD LED screen, high brightness, and high contrast, high resolution.
Compatible USB playback function, including video, pictures, MP3 players and other various playback mode.
Multimedia function, this product have various interface: HDMI, USB, etc., compatible and easily connect a variety of peripheral devices.
The speed of touch up to 300 points, writing smooth, fast response.
Support single point touch, the mouse control, multi-touch, available to different situation.
Can be used with a variety of software, to adapt to a variety of applications.
|
Product Description |
|
LCD panel |
|
|
Diagonal Size |
42" |
|
Aspect Ratio |
16:9 |
|
Pixel Pitch |
0.4845(H) x 0.4845(W) |
|
Response Time |
5ms |
|
Resolution |
1920x1080 |
|
Contrast Ratio |
1300:1 |
|
Brightness (cd/m2) |
450d/m2 |
|
Active display area |
930.24 (H) x 523.26(V) |
|
Display Color (Max) |
16.7M |
|
Viewing Angle(U/D,L/R) |
H:178o V:178o |
|
PC system |
|
|
CPU |
Intel 1037U (I3,I5,I7 option) |
|
Chipset |
Intel chipset |
|
Graghpic Chipset |
Integrated graphics |
|
Memory |
2G(4G/8G/16G option) |
|
Hardisk |
500G(Option: SSD) |
|
Lan |
10M/100M |
|
WIFI |
Option |
|
Audio |
|
|
Stero Speaker |
2x10W |
|
PC system I/O |
|
|
USB 3.0 |
X2 |
|
USB 2.0 |
X2 |
|
Lan(RJ45) |
X1 |
|
Audo Output |
X1 |
|
Mic |
X1 |
|
DisplayPort output |
X1 |
|
HDMI output |
X1 |
|
RS232 port |
Option |
|
VGA output |
Option |
|
Touch parameters |
|
|
Inductive technology |
Infrared Single/Double touch |
|
Touch point |
1~32 points |
|
Inductive objects |
Finger,pen, any other non-transparent objects |
|
Inductive size |
Diameter≥5mm,recommended size≥7mm |
|
Resolution |
4096*4096 |
|
Response time |
Dual touch:first click:8ms,continuous:8ms |
|
Single touch: first click: 8ms,cintinuous:3ms |
|
Cursor speed |
Single: highest 300 dot/s, dual touch:125 dots/s |
|
Operating life |
≥60,000,000 times to touch |
|
Multi Touch |
Support Wind7/8 |
|
Positioning calibration |
Support HID device, plug and play, no need driver and calibration, match-management program for positioning calibration. |
|
Light anti-decay |
light anti-decay circuit, maitains stable performance for a long-time working |
|
Anti-light interference |
Can work in the condition of direct sunlight |
|
Technical Specification |
|
|
OSD language |
Simplify Chinese, English |
|
Horizontal Frequency |
20 ~ 82KHz(Anolog&Digital) |
|
Vertical Frequency |
55~75Hz |
|
Optimum Resolution |
1920x1080 at 60HZ |
|
Native Resolution |
1920x1080 at 60HZ |
|
Supported Resolutions |
1920x1080;1680x1050; |
|
1440x1050;1360x768; |
|
1280x1024;1280x768; |
|
1024x768; 800x600; |
|
720x400; 600x480; |
|
Video Modes(no tuner) |
480i;480p;576i;576p; |
|
720p(50 / 60HZ); |
|
1080i(50 / 60HZ); |
|
1080p(50 / 60HZ); |
|
Operation/Sotrage |
|
|
Operating Temperature |
00C~400C |
|
Operating Humidity |
10%~90% |
|
Storage Temperature |
-200C~600C |
|
Storage Humidity |
0%~90% |
|
Features and Benefits |
|
|
System voltage detection |
POP/PIP |
|
CPU/temperature detection system |
Image automatically adjust |
|
CPU fan speed detectionsystem |
Manually adjust the image position |
|
CPU smart fan control |
Color automatically adjust |
|
Intel? Smart Connect |
Color manual adjustment |
|
Intel? Quick Sync 2.0 |
white balance adjustment |
|
Intel? Rapid Start |
ADC adjustment |
|
Support DirectX 11 |
3D decoding |
|
Support DisplayPort |
3D comb filter |
|
HDMI new technology |
3D noise reduction |
|
Anti-static, magnetic field, strong electric field |
Double to interlaced 3D |
|
Intelligent cooling system |
3 d light (Y/C) separation |
|
Low energy consumption backlight system |
3D color management |
|
Brightness adjustment |
3D edge serrated processing |
|
Touch conotrol |
3D images of static/dynamic compensation |
|
Toughened glass protection |
Screen freezes function |
|
POWER |
|
|
Power supply: |
AC 100~240V(+/-10%)/50-60Hz |
|
Power consumpiton: |
≤350W |
|
Stand-by: |
≤1W |
|
Safety and Ergonomics |
|
|
Quality standards:ISO9001,CCC,FCC,CE,ROHS |
|
Environmental standards:All components,accessories are compliant with international standards. |
|
|
Optional accessories |
|
|
Card reader |
DP cable(1.5m) |
|
WIFI module |
VGA cable(1.5m) |
|
3G module |
HDMI cable(1.5m) |
|
Accessories |
|
|
Touch pen * 2 |
User manual * 1 |
|
Wall mount * 1 |
Power cord *1 |
|
Mechanical Spec |
|
|
Hole for wall mount: |
/ |
|
NW/GW: |
30kg/35kg |
|
Dimension(W/O stand): |
1009*602*80mm |
|
Packing Dimension (1 pcs/ctn): |
1100*700*180mm |
|
Warranty |
|
|
13 months (LCD monitor and components) |
