| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
TFT |
| Application: |
Advertising |
Product Description
4-wire analog resistive touch technology is suitable for applications that require ease of integration, low power consumption, lightweight, portability, cost effectiveness and compact mechanism. Affordable, durable and versatile, the 4-wire resistive touch screens are primarily used in mobile applications, such as smart phones, PDAs, e-books, web pads, digital cameras, GPS, and other consumer or office electronics.
Specification
Circuiting Rating: 5V DC, 35mA Surface Hardness: 3H
Light Transmission: Film+Film>77% Hitting Life Expectancy: Over 1 million
Film+Glass>83% Scoring Life Expectancy: Over 100, 000
Contact Bounce: <10ms Operating Temperature: -10 oC ~+60 oC
Resolution: 4096x4096 Storage Temperature: -20 oC ~ +70 oC
Linearity: 1.5%(<1.0% By Request) Choices of Glass Thickness: 0.7mm, 1.1mm, 2.0mm, 3.0mm
Operating Force: 10g~100g Choices of Glass: Normal Glass, Chemically strengthened glass
Features:
Input Method: Stylus, Finger, Gloved Hand
Widest Range in Sizes: 6.5" ~ 22"
High Transmission Rate
Low Power Consumption
Narrow Boarder Design
Writing and Signature Capture Capability
Constructions: Film/Glass
Sunlight Readability Available
Palm Rejection Model Available
RoHS Compliant
One Year Warranty
Eagle Touch Technology is a Hi-tech enterprise. Which devoted to the research and development of touch screen technologies and touch series products and also concentrate on the manufacturing and selling "eagle-touch" brand touch screens. Our products has been selling to all over the world such as west Europe, North America and Southeast countries and got good reputation from our clients.
"Eagle-touch" touch series products involves in many touch filed and has been widely used in industry, finance, medicine, POS, retail chain, services, tourism, transportation, office automation and other industries by years of product design and manufacturing. And we also provice OEM service!
Looking forward for the chance to working with you!
