4 Channel High Voltage Power Amplifier (Sanway FP2400Q)

4 Channel High Voltage Power Amplifier (Sanway FP2400Q)
Price: US $ 500-1000/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: T/T,Paypal,Money Gram,Western Union
Prod Model: Sanway FP2400Q
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
8ohms Stereo Power(RMS): 4X450W
Class: Td
Type: Professional Amplifier
Function: Amplifier Combined
Tube Type: Transistor Amplifier
Voltage: AC 220V
Element Number: Push-Pull Amplifier
Output Number: 4
Used For: Professional
Usage: KTV System
Sound Channel: 4.1
Conductive Mode: Td Class

Product Description

FP2400Q 4 Channel High Voltage Power Amplifier

4X450W@8ohmsohm Switching Supply Power Amplifier ( FP2400Q)
Switching Supply Power Amplifier ( FP2400Q)

1.4X600W@2ohm Audio Power Amplifier
2. Lightweight Switching Power Amplifier
3. FP2400Q High Power Amplifier

Specifications:

FP2400Q 4 Channel High Voltage Power Amplifier
ITEM FP2400Q
Output Power 20-34kHz, 1W with 1 KHz
8ΩStereo Power(RMS) 450WX4
4ΩStereo Power(RMS) 550WX4
2ΩStereo Power(RMS) 600WX4
8ΩBridged Power(RMS) 1100WX2
4ΩBridged Power(RMS) 1200WX2
Frequency Response(+o/-0.3dB,1W/8Ω) 20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W <0.1%
Signal-to-Noise Ratio >112 dBA
Channel separation (Crosstalk) at 1 kHz >70 dB
Input Connectors (per channel) 3-pin XLR, electronically balanced
Output Connectors (per channel) Binding Posts 2-pole
Class TD
TourClass Protection short circuit, DC voltage, turn-on/off transient, current inrush
Operating voltage 130-265 V / 65-135 V selectable
Voltage Gain(dB) 23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance 20 Kohms
Level adjustment (per ch.) Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions (W×H×D) 483×88×396mm
Packing dimension 580×180×560mm
Net weight(kg) 13
Gross weight(kg) 18

Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.

With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.

Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.

Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.

Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.
