| Prod Model: |
TFT054A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| ODM: |
OEM Product Design/ Production |
| Certification: |
RoHS and ISO 9001:2008 Certification |
| LCD Type: |
TFT Transmissive Normal White |
| Driver Element: |
a-Si TFT Active Matrix |
| Number Of Dots: |
480*(RGB)*272 |
| Active Area: |
53.86 *95.04 |
| Viewing Direction: |
12 O'clock |
| Driver IC: |
Ili6480bq |
| Module Size(W*H*T): |
67.2X105.5X4.1 |
| System Interface: |
24 Bits RGB Interface |
| Application: |
Graphic Design |
| Aspect Ratio: |
4:3 |
| Feature: |
With Remote Control |
| Type: |
TFT |
| Widescreen: |
Not Widescreen |
| Response Time: |
10ms |
| 3D: |
Not 3D |
| Screen Size: |
4.3 |
| Optimum Resolution: |
480X272 |
| Interface Type: |
RGB |
Product Description
LCD Type TFT Transmissive Normal White
Driver element a-Si TFT Active matrix
Number of Dots 480*(RGB)*272
Pixel Arrangement RGB Vertical Stripe
Active Area 53.86 *95.04
Viewing Direction 12 O'clock
Driver IC ILI6480BQ
Module Size(W*H*T) 67.2x105.5x4.1
System interface 24 BITS RGB interface
| Model NO. | TFT054A |
| lcd size | 4.3 inch |
| Size:Length*Width*Highth: | 105.5*67.2*4.1 |
| Interface | RGB |
| Resolution | 480*272 |
| (luminance)cd/m² | 200 cd/m² |
| with or without touch panel (TP) | 4&5Wire Resistive Touch(Optional) |
| LED light | 10LED |
| FPC PINs | 40 |
| Diver IC | ILI6480 |
| Supply Voltage Of Logic | VDD -0.5 To 5.0V |
| Work Temp | -20 To +70c |
| Storage Temp | -30 To +80c |
| Viewing Angle | 12 O' Clock |
| Related products | 2.8" 3.2" 3.5" 4.3" 5" 5.6" 7" 8" 9" 10.1" 17" |
| LCD Module application | Game Machine.Car Audio DVD.GPS.cash register.Industial Automation.Office Automation.MedicalEquipment.LCD Monitor.DVDPlayer.POS machine. etc. |
We specialized in sales of LCD/LCM/TFT liquid crystal displays. Its products are widely used in electric power terminal, numerical control, Instrumentation, medical equipment, security, tax control equipment Industrial automation and other fields.
The company can provide various specifications of TN, STN, FSTN. TFT LCD screens and solutions.
Hunan Huayuan Display Technology Co. Ltd., and Shenzhen Huayuan Display Technique Co. Ltd., which are wholly owned subsidiaries of Huayuan holding, is responsible for the R & D, production and sales of all kinds of LCD, LCM liquid crystal displays.
Hunan Huayuan Display Technology Co., Ltd. is located in Zhuzhou high tech Zone, Hunan Province. The plant area occupies 6000 square meters, with a 100000 grade purification workshop, 2 automatic SMT production lines, the aging room, laboratory and other supporting facilities. The company has a professional R & D team with high quality and high education. At the same time it has a close cooperation with Hunan University, Hunan University of
Technology and other famous domestic universities, research Institutions to focus on R & D, production of various specifications of TN, STN, FSTN, TFT modules, and a variety of customized LCD displays.
Huayuan Holding always adheres to the business philosophy of "innovation, excellence, integrity and dedication, " and strives to make the company become a global well-known enterprises.
