30inch Elongated LCD Display
| Price: |
US $ 1000/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,D/P,Paypal |
| Prod Model: |
DE300TXP01 |
| Application: |
Bus/Car AD Player |
| Screen Size: |
30-40 Inches |
| Type: |
Network Version AD Player |
| Touch Screen Type: |
Infrared |
| Screen Technology: |
LCD |
| Interface Type: |
D-Sub(',VGA) |
| Remote Control: |
With Remote Control |
| OS: |
Android |
| Customized: |
Customized |
| Installation: |
Ertical Wall-Mounted Combined |
Product Description
DE300TXP01 is a 30.0" TFT Liquid Crystal Display module. This module supports 1366 x 512 WXGA.format and can display 16.7M (8-bit/color) colors.
| CHARACTERISTICS ITEMS | | SPECIFICATIONS |
| Screen Diagonal[in] | | 30" |
| Pixels[lines] | | 1366* 512 (16 : 6) |
| Active Area[mm] | | 697.6845 (H) x 261.504 (V)( 30" diagonal) |
| Sub -Pixel Pitch[mm] | | 0.17025 (H) x 0.51075 (V) |
| Pixel Arrangement | | RGB vertical stripe |
| Weight[g] | | TYP. 3950 |
| Physical Size[mm] | | 739 (W) x 304 (H) x 24.7 (D) Typ. |
| Display Mode | | Transmissive mode / Normally black |
| Contrast Ratio | | 3000:1 Typ. |
| | | (Typical value measured at CMI's module: RX300TXP01 |
| Glass thickness (Array/CF)[mm] | | 0.7 / 0.7 |
| Viewing Angle (CR>20) | | +88/-88(H),+88/-88(V) Typ. |
| Cell Transparency | | (Typical value measured at CMI's module: RX300TXP01) |
| | |
| Polarizer (CF side) | | Super Wide View Anti-glare coating, 739(H) x 304(W) |
| | | Haze:11% Hardness:3H |
| |
