2u 600W 2 Inch Professional High Power Audio Amplifier (QA5106)
| Price: |
US $ 130-230/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,D/P,Paypal,Money Gram,Western Union |
| Prod Model: |
QA5106 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand: |
Qsn |
| RMS: |
600W |
| Protection: |
Overheat Protection |
| Type: |
Professional Amplifier |
| Function: |
Post Amplifier |
| Usage: |
Outdoor,Pubs,Stage |
| Voltage: |
AC 220V |
| Element Number: |
Push-Pull Amplifier |
| Used For: |
Professional |
| Conductive Mode: |
AB |
| Tube Type: |
Transistor Amplifier |
| Output Number: |
2 |
| Sound Channel: |
2.0 |
Product Description
1)The QA series amplifier are using the famous OnSemi transistors.
2)Also it using the special good quality capacitor and electrolysis.
3)It adopts SMT technology.
4)The fans are intelligent fans and it can reach silence working which can be used in the concert
5)The QA amplifier has perfect dynamic limiter system,it can protect the speaker system very nicely,also it can insure the sound
6)The circuit protection way is fully,also can be worked at extremely conditions.
7)The amplifier can be worked at bridged mode.
Model | QA5145 | QA5106 | QA5108 | QA5110 |
| 8ohms Stereo | 450W | 600WX2 | 800W | 1000WX2 |
| 4ohms Stereo | 800W | 950WX2 | 1350W | 1650WX2 |
| 4ohms Bridged | 1600W | 2200W | 2800W | 3400W |
| Low cut | 30Hz Low cut |
Frequency
response | 20Hz~20KHz(+-0.3dB) |
| sensitivity | 0.775V/1.0V/1.44V |
| work mode | Stereo/parral/bridged
|
| fans working way | intelligent speed adjustment
connector(each channel) |
| input connector | XLR(6.3&) |
| output connector | NL4 speakon connectors |
| balance input | 20K |
| unbalance input | 10K |
| mixed voice reduction | ≥60dB |
| RMS 8ohms | ≥103dB |
| damp factor | ≥650 |
| THD | ≤0.08% |
Position
response | ±10° |
| speed rate | ≥25V/μs |
| Output circuit Mode | Class AB | Class H+ |
| Net Weight | 19KG | 21KG | 25KG | 27KG |
| Product size | 484W × 380D × 88H | 484W × 460D × 88H |
| package size(mm) | 590W × 520D×145H | 590W × 600D×145H |
| Protect | Full |
Guangzhou YunQiang Electronics Co., Ltd. is a professional audio manufacturer which has R& D, Production department, Marketing Dept., and Technical and service Dept.,
The main products include: Power Amplifier, Karaoke amplifier, Professional Speaker, Karaoke speaker, Sound Mixer, Audio processor and Conferencing systems.
Nowadays, in professional sound industry, more and more people are seeking for amplifiers with light weight, high power output, high sound quality and high stability.
To get good sound quality, we should have high quality components. And to ensure the stability, we must solve the problem of heat dissipation. Now, we have this amplifier FP14000, FP10000Q, FP-8000Q. Our FP14000, FP10000Q, FP-8000Q is Class TD switching amplifier fixed with NOVER (from UK) power capacitors, ON-Semi power transistors other high quality electronic spare parts. Professional circuit design and actual copper heat sink with better structure make fast heat dissipation possible. And fast heat dissipation contributes to high stability of the amplifier. Once you have our amplifiers at your hands, open the chassis, you will find artwork and detail difference. The swich power amplifier can be used to drive line array loudspeaker systems in touring, living show and other applications with high requirement on sound quality and stability.
Since the foundation of our enterprises, we have been concentrating on designing new products, doing research on new sound technology, training our staff, as well as improving our quality to products and management system. And now we have had a unique management experience, advanced production equipment, abundant design capability, and the large marketing network and after-sales service system.
Now we have passed newest CE, FCC, RoHS, SGS, CCC, ISO9001 on March, 2015.
