| Prod Model: |
CR-G21HD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| RF Signal: |
ROM:1GB |
| Screen Type: |
Capacitive |
Product Description
More products available:
CR-Wireless G8C/G 8pip 10.1 inch handheld wireless programmable touch screen
Features
1) Support barrier-free zone wireless transmission distance up to 50m.
2) Support TFT true color LCD, support 16: 9 high resolution color (18 bit color depth) widescreen for high clear display.
3) Operation interface can be customized by the user, PNG, JPG and other commonly used image format, graphical interface support text, 3D button, polymorphism, irregular button effects, vivid and beautiful user interface.
4) Simply touch screen can realize free control.
5) Support for handhold mobile use.
type
parameters |
CR-Wireless G7C |
CR-Wireless G7pip |
CR-Wireless G8C |
CR-Wireless G8pip |
|
Display |
TFT LCD full color |
TFT LCD full color |
TFT LCD full color |
TFT LCD full color |
|
Touch screen resolution |
800X480 |
800X480 |
1024X600 |
1024X600 |
|
Control mode |
Wireless |
Wireless |
Wireless |
Wireless |
|
Touch screen size |
8inch |
8inch |
10.1inch |
10.1inch |
|
Scope |
Can access CR-PGM II, CR-PGM III control system |
Can access CR-PGM II, CR-PGM III control system |
Can access CR-PGM II, CR-PGM III control system |
Can access CR-PGM II, CR-PGM III control system |
|
PIP switch |
no |
yes |
no |
yes |
|
Communication Interface |
USB interface |
USB interface |
USB interface |
USB interface |
|
Memory |
1G |
1G |
1G |
1G |
|
Wireless transmitter frequency |
433MHz |
433MHz/5.8GHz |
433MHz |
433MHz/5.8GHz |
|
Remote control distance |
100m (barrier-free) |
100m/<100m(barrier-free) |
100m |
100m/<100m(barrier-free) |
|
External power supply |
DC 12V/3.3A |
DC 12V/3.3A |
DC 12V/3.3A |
DC 12V/3.3A |
|
Battery |
|
Battery capacity |
7.4V/4400mAh |
7.4V/4400mAh |
7.4V/4400mAh |
7.4V/4400mAh |
|
Charge saturation time |
5h |
5h |
5h |
5h |
|
Charge the battery temperature |
0°C ~50°C |
0°C ~50°C |
0°C ~50°C |
0°C ~50°C |
|
Battery Specifications |
Lithium-ion rechargeable battery 7.4V
|
Lithium-ion rechargeable battery 7.4V
|
Lithium-ion rechargeable battery 7.4V
|
Lithium-ion rechargeable battery 7.4V
|
|
Other specifications |
|
Dimensions (mm) |
236LX154.2WX78H |
236LX154.2WX78H |
291LX175WX78H |
291LX175WX78H |
|
Weight |
About 1KG |
About 1KG |
About 1.2KG |
About 1.2KG |
