| Prod Model: |
LP654166-2000-P |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Warranty: |
One Year |
| Type: |
Lithium-Polymer Battery Pack |
| Connection Mode: |
Series and Parallel |
| Standard Voltage: |
3.7V |
Product Description
654166 Lithium Polymer Battery Pack ( 3.7V 2000mAh )| Voltage | 3.7v |
| Capacity | 2000mAh |
| Size | Customzied |
Quick Detail:Brand Name: QUAWIN/OEM
Product number: LP654166-2000-P
Type: Rechargeable li-polymer battery, Lithium Polymer Battery Pack, li-ion battery, Rechargeable battery, Li-ion rechargeable battery, Rechargeable Li-ion battery, 3.7V Batteries, 3.7V rechargeable Batteries, 3.7V Batteries Rechargeable, Battery cells Li-ion, Li-ion battery cells, Li-ion battery cell
Place of Origin: Guangdong China (Mainland)
Nominal Voltage: 3.7V
Nominal Capacity: 2000mAh
Offered: OEM/ODM Service, After-sales Service.
Pack: Blue PVC Shrink Tube
Size: 6.5(T) x 41(W) x 66(H)mm(with PCM)
Weight: 60g
Composed Type: 1S1P
Delivery time: 5-7days
Cycle life: 500 times
Warranty: 12 months
Packing: Antistatic bag /white box and standard export carton/customized
Packaging & Delivery:. Netural labels, Polybag, PVC, Color box, Customised package
. Netrual packing/Carton box with less than 10KGS
. Delivery Detail: Sample within 3 work days, 7~15 days for bulk order
Specifications:Product Name: 654166 Lithium Polymer Battery Pack
Product number: LP654166-2000-P
Voltage: 3.7V
Capacity: 2000mAh
Maximal charging current: 2A(Adjust)
Life of battery: About 500 times cycle
Charging temperature(º C): 0º C~45º C; 32oF~113oF
Discharging temperature(º C): -20º C~60º C; -4oF~149oF
Storage temperature(º C): -20º C~45º C; -4oF~113oF
Dimensions(mm): 6.5(T) x 41(W) x 66(H)
(as per customers'requirements)
Weight(g)About 60g
Over charger protection voltage(V): 4.2V± 0.05V
Over discharge protection voltage(V): 3.0V± 0.25V
Protection Temperature(º C): 70º C± 5º C
Warranty: 12 month (free)
Requirements: With label, plug, connector, OEM accept.
Specification: High capacity, high discharge long work, life long, save and environmental protection.
Application: Wifi device, communication device, medical equipment, instrument, led lamps, transportation sign, portable family appliance, electronical tools and toys etc.
The Suitable Charger Model NO.: QW037-030-L
Charger input: 100V~240VAC 50-60Hz
Charging mode: Constant voltage constant current (CC/CV)
Charging voltage: 4.2V± 0.2V
Charging current: 3.0A± 0.1A
Charging time: 6-7 hrs(standard)
Charger working instruction: Be in charging the red light, be full of charging the green light.
Product Advantages:1). Green product
2). Long standby time
3). One year warranty
4). Excellent safety performance
5). Excellent storage performance and low self-discharge rate
6). Short circuit testing passed
7). Overcharge testing passed
8). Over discharge testing passed
9). 100C thermal shock test passed
10). 1.2m drop testing passed
Spotlight:1). Provide both single cells and battery packs
2). 100% inspection before delivery
3). Inspects inner resistance, discharge platform and self-discharge
4). Tablished quality control systems under ISO9001
5). Stomized packs, tags, labels, plugs, connectors, over current protection,
Temperature cont8. L protection are available
Shipping terms:1). Samples checking: Sending by Express ( DHL/UPS/FEDEX/TNT, by air)
2). Bulk production: Sending out by cargo shipping / air freight/Express(DHL/UPS/FedEx/TNT), or we can accept other shipping terms according to your requirements.
3). We are not responsible for any accidents, delays or other issues that are caused by the shipping.
Safety Precaution:1). Do not throw battery into water or make it wet;
2). Keep the battery away from heat source(like fire or heater);
3). Do not throw the battery into fire or heat the battery;
4). Forbid to hammer to trample the battery;
5). Forbid disassembling the battery in anyway
