| Prod Model: |
89227701 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Outline Size(Mm): |
60.5(L)*47(W)*2.027(T) |
| Active Area(Mm): |
55.01(W) X 27.49(H) |
| Viewing Angle Range: |
160° |
| Color: |
Yellow |
| LCD Drive Mode: |
Multiplex Drive LCD Module |
| Type: |
Graphic |
| Usage: |
Monitor LCM |
| Viewing Angle: |
TN＋FILM |
| Customized: |
Customized |
| Touch Screen Type: |
Customized |
| Display Technology: |
OLED |
Product Description
Product Name:
2.4 inch OLED display for home application
Product No. :
89227701
Product Discription:
Product Advantages:
1. Self-lighting display, without backlight, being positive or negative, visible in dark condition
2. higher contrast than traditional display device
3. Be visible with any orientation
4. Higher response speed than traditional display, the response speed won't change with low temperature, whose response time is 1/1000 of LCD
5. Wider operating temperature, advantageous for extreme condition, especially for super low temperature
6. No liquid material ,be better anti-shocking and anti-throwing
7. Not only monochrome display but also colorful display as TFT
Product Delivery:
Delivery Details: 1 to 30 days. The delivery fee is up to the weight and volume of the products.
Product Parameter:
Size 2.4"
Model 89227701
outline size(mm) 60.5(L)*47(W)*2.027(T)
Active Area(mm) 55.01(W) x 27.49(H)
matri x128x64
viewing angle range 160°
dot size 0.4mm x 0.4mm
color Yellow
response speed 10uS
contrast 2000 : 1
storage temperature -40~+85°C
operating temperature -40~+70°C
module weight TBD
interface 8Bit 6800/800parallel port,SPI3/4serial port
Interface PIN and PITCH23PIN 0.3mm
luminance 70 CD/m²
consumption 399mW
Life time (luminance decrease to less than 50% of initial)40000 Hrs
Packaging & Shipping:
Packaging: In general, foam or anti-static tray inside, carton outside
Delivery: For mass production, the delivery time is around 4-6 weeks.
Competitive advantages:
1)Over 27 years of production experience
2)Top quality with RoHS, REACH, Lead Free
3)ISO9001 certificated Factory supplied
4)Competitive price and Short lead-time
5)In stock, samples lead-time: 3~7 days.
Specifically, the main products include:
1) TN/STN/FSTN/ASTN LCD panels
2) Segment LCD modules
3) Character and graphic LCD modules
4) 2.5~7.0 inches color TFT-LCM
Presently, we are looking forward to even greater cooperation with overseas customers based on mutual benefits. Please feel free to contact us for more details.
|
Size |
2.4" |
|
Model |
89227701 |
|
outline size(mm) |
60.5(L)*47(W)*2.027(T) |
|
Active Area(mm) |
55.01(W) x 27.49(H) |
|
matrix |
128x64 |
|
viewing angle range |
160° |
|
dot size |
0.4mm x 0.4mm |
|
color |
Yellow |
|
response speed |
10uS |
|
contrast |
2000 : 1 |
|
storage temperature |
-40~+85°C |
|
operating temperature |
-40~+70°C |
|
module weight |
TBD |
|
interface |
8Bit 6800/800parallel port\SPI3/4serial port |
|
Interface PIN and PITCH |
23PIN 0.3mm |
|
luminance |
70 CD/m² |
|
consumption |
399mW |
|
Life time(luminance decrease to less than 50% of initial) |
40000 Hrs |
Shenzhen Jinghua Displays Co., Ltd was established in 1987 as a professional LCD, LCM, Touch Panel and Cover Lens manufacturer. We also provide SMT / OEM / ODM services. Our strategic positioning is to be a professional supplier for human-machine interface. We have already become China National High-Tech Enterprise and the Vice President of China LCD Industry Association.
Innovation, High Quality, Trust, Environment Protection, Service, Safety, those are our Value orientation. Our customers are those enterprises who are looking for high quality, unique products, innovated technology and valued service. As we have stable finance status and excellent management group, a rich variety of new products, good service, and as we keep promises, follow environmental protection law, take social responsibility, we have a very good reputation. In this way, we have won praise from our customers all over the world.
We JHD have a stable design and development team for 30 years to provide our customers a completed ODM and OEM industrial product design and manufacture service. We can also provide a total solution service, from product concept, component structure design, mold making to embedded software custom developing and finished sample delivery. We keep developing new materials, searching new technology, pushing new products and applying for technology patent. Now we can provide a completed custom Human-machine interface solution, in automotive, Medical, industrial area, etc.
At our high-tech plants. Our advanced production, processing and on-line inspection systems are imported from Japan and the U. S. A. Monthly production capacity is in excess of four million LCD panels and modules.
We were certificated ISO9001 compliant by SGS in April 1997. We guarantee on-time delivery and excellent customer service to meet the demands of our clients. We will continue to place our main emphasis on technological innovation, product improvement and quality assurance.
