12 Inch Bus/Board Video LCD Display
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,EXW |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
| Prod Model: |
VV-12A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Display Panel: 12-Inch TFT LCD: |
Panel Ratio: 4:3 |
| Best Resolution: 800 X 600 Pixels: |
Luminance: 250CD/M2 |
| Single Interface: VGA/AV/BNC (Optional): |
S-Systems: PAL and NTSC |
| Type: |
LCD Monitor |
| Material: |
LCD |
| Color: |
Color |
| Screen: |
General Screen |
| Size: |
8-20" |
Product Description
Specifications:
Specifications:
Display panel: 12-inch TFT LCD monitor (4: 3)
Best resolution: 1280X768 pixels
Contrast ratio: 600: 1
Luminance: 400 CD/m2;
Viewing angles:
Horizontal: 160°
Vertical: 140°
Refresh rate: 60 to 75Hz
Single interface: VGA/AV/BNC (optional)
S-systems: PAL and NTSC
Panel backlight: CCFL double-light
Image reversed: Not supported
Power adapter:
Input: 110 to 220V
Output: 12V
Weight: 2.2kg
Dimensions: 30 X 25.5 X 4.5cm
Unit packing weight: 2.6kg
Unit packing dimensions: 31.5 X 11.5 X 3cm
Carton weight: 26.2kg
Carton box dimensions: 60 X 32.5 X 62.5cm
Menu languages: English, Russian, French, Spanish, German, Italian and Chinese
Supports VGA/RCA/BNC (optional)
Built-in speaker with earphone jack to connect with earphone or sound box
Ultra-thin design
Accessories:
User's manual, warranty card, stand, BNC and VGA cable (BNC input)/VGA cable and TV cable and remote control (TV input), AC power adapter
Main applications:
Microscopes, endoscopy, flatness detectors, dimensional detectors, hot press, BGA rework stations, laser engraving equipment, laser marking machines, rocker cameras, CCTV monitors and POS
Vast vision industry Co., Ltd, Established in 2004, is a high-tech enterprise specialiazed in development, production and marketing of LCD/LED monitors and modulaes. We our campany emphasize small size ranging froam 2.4" to 20.1", can offer OEM/ODM service.
As a professional manufacture and exporters, we gain much honor in various field, u can see our monitor in security monitoring, hospital, supermarket, bank, on bus/car/truck/board, factory production line, BGA station, laboratory and some other special circumstance.
