| Prod Model: |
P10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Display Type: |
LED Video Display |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Scanning Mode: |
1/8 Scan |
| Application: |
Meetings |
| Pixel Pitch: |
10mm |
| IP Rating: |
IP43 |
| Certification: |
FCC, CB |
| Pixel Density: |
10,000 dots / m² |
| System Operating Platform: |
WIN XP |
| Pixel Configuration: |
SMD3528 |
Product Description
Features
1. Low noise, good cooling, low power consumption, reliable
2. Keep its beatiful pictures and brightness after using for a long time
3. Energy-saving design, rich colors, smooth pictures and good conformity
4. Wide view angle, it keeps its real and wonderful colors from different angles
5. High refresh rate, high gray scale, no flickering, can be used for live TV show
LED System Diagram
|
NO. |
Item |
Parameter |
|
1 |
Model |
P10 |
|
2 |
Pixel pitch |
10mm |
|
3 |
Pixel configuration |
1R1G1B |
|
4 |
LED type |
SMD3528 |
|
5 |
Module size |
320*160mm |
|
6 |
Module resolution |
32*16 |
|
7 |
Cabinet resolution |
64*64 |
|
8 |
Cabinet size |
640*640mm |
|
9 |
Density |
10000dots/m2 |
|
10 |
Brightness |
1000NIT |
|
11 |
Scan method |
1/8 |
|
12 |
Best view distance |
≥6m |
|
13 |
Max. power consumption |
600W/m2 |
|
14 |
Ave. power consumption |
300W/m2 |
|
15 |
Weight |
43kg/m2 |
|
16 |
Cabinet weight |
18.4kg |
|
19 |
Refresh rate |
1600Hz |
|
17 |
Grey scale |
4096 levels |
|
18 |
Colors |
6.87 trillion |
|
20 |
View angle |
Horizontal: 120°, Vertical: 120° |
|
21 |
Color temperature |
6500K |
|
22 |
Frame frequency |
≥60Hz |
|
23 |
Out of control pixel rate |
<1/10000 |
|
24 |
MTBF |
>5000 hours |
|
25 |
Lifespan |
50000 hours |
|
26 |
Control mode |
Synchronous display with control PC by DVI |
|
27 |
Working voltage |
AC 100/200v 50-60Hz |
|
28 |
Control distance |
Ethernet cable: 100m, Multi-mode optical fiber: 500m, Singel-mode optical fiber: 20km |
|
29 |
Operation temperature |
-20 to +50 |
|
30 |
Operation Humdity |
10% to 80% |
|
31 |
Protection level |
IP40 Front, IP21 rear |
