Prod Model: |
W2-D8900G |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Type: |
Car Radio |
Certification: |
CE |
Placement: |
Dashboard |
Product Description
Special Features:
Capactive Touch Screen
DSP Audio/4.1 channel Audio output
Front DVR Camera-Operate by Touch Screen of DVD (High Solution & Speed)
Support External WiFi Dongle
Support External 3G Dongle
Support OBD Display-Operate by Touch Screen of DVD
1080P HD Video Display
Support Max 32GB SD/USB/HD
Audio Copy From CD to SD/USB
Auto Rear Viewing Function
FM/AM Tuner /RDS
Bluetooth Function
iPod/iPhone Ready
Built-in HD GPS/Dual Zone System
Unique 3D Flash Graphical User Interface
Mirror Link Function
Steering Wheel Control Support
===================================================================
We hightly suggest you watch the following videos, you will see how it working.
( just copy link and search on any browser )
Main Functions Video Introduction:
1. How to change the start logo: Youtu. Be/RajNL-lGHMc
2. How to change the radio area: Youtu. Be/_Wnu1CiQHS8
3. How to setup the NAVI software path: Youtu. Be/4luDZoYfA80
4. DVD Disc Playing: Youtu. Be/UhsouLEA908
5. MP3 Disc Playing: Youtu. Be/scKl24ldVtM
6. iPod Playing: Youtu. Be/DyO4EFUpm0k
7. Radio Function: Youtu. Be/XKy3Zs7TdEo
8. SD Playing: Youtu. Be/MKYiczESKTk
9. USB Playing: Youtu. Be/7eOpoXwe4KI
10. DVR Camera Menu: Youtu. Be/0lntpOVzSd8
11.3G Modem Connection: Youtu. Be/WXhvPMmqq10
12. DSP-EQ with 10 Band Qualizer and Subwoofer Setting: Youtu. Be/m78NokG2RTk
13. SETUP Menu Introduction: Youtu. Be/NXWooXg2_JI
14. OBD Menu: Youtu. Be/5qEMjauzvag
15. Mirror Link: Youtu. Be/BB5Le5wGrzo
Video Show In The Car When Driving:
1.3G Internet Connection: Youtu. Be/dcrgGjSXwJ8
2. Bluetooth Music(A2DP)Playing from Mobile: Youtu. Be/fOoT_H9QkGs
3. Bluetooth+Phone Book: Youtu. Be/tSGLAkQn_a0
4. DVR+OBD: Youtu. Be/ypfwyvoifFI
5. Front DVR Camera: Youtu. Be/woTNmWi-N1A
6. Panel BUTTON Function: Youtu. Be/ULY6RWnsfJw
7. OBD Function: Youtu. Be/SLyti4hOF90
8. RADIO, DVD, SD Card Function: Youtu. Be/kmQzDq1PVA8
9. USB: Youtu. Be/TInwVhkUpZY
GPS |
Operating System | Windows CE 6.0 |
GPS Resolution Output | 800x480 |
Media Player | No |
Card Supported | micro SD card |
MAX Memory Supported | 16GB |
Map Supported | PolNav, Igo, Route66, Tom-Tom, Support 3D Maps |
GPS Baud Rate=9600, Com Port=2 |
Display Screen |
Screen Type | Digital TFT touchscreen |
Resolution | 800*480 |
Screen Dimension | 6.2 inch 16:9 |
Language |
Main Interface Language | English, Deutch, Francais, Português, Italian, Espanol,Turk,etc. |
DVD Control Language | English, Deutch, Franch, Português, Spanish, Latin, Espanol,etc. |
GPS Console Language | English, Deutch, Francais, Português, Italian, Espanol,Turk,etc. |
DVD Playback |
Disk Format Supported | DVD/VCD/CD/MP3/MPEG4/CD-R/WMA/JPEG |
Media | DVD/DVD-R/DVD+R/DVD-RW/DVD+RW/CD/CD-R/CD-RW/MP3/MP4(DIVX)/VCD/SVCD |
Bluetooth |
A2DP | Yes |
Microphone | Built-in |
Received Call | Yes |
Dialled Call | Yes |
Missed Call | Yes |
Download Contacts | Yes |
Store Contacts | Yes |
TV Tuner |
Built-in Analog TV | Yes |
Analog TV System | NTSC, PAL-B/G, PAL-I, PAL-D/K,SECAM-BG,SECAM-DK,SECAM-L |
Built-in DVB-T Tuner | No |
DVB-T Format | / |
Built-in ISDB Tuner | Optional |
Radio |
AM Frequency Range | 522-1620 (Europe), 530-1710 (America),522-1620 (Russia), |
FM Tuning Range | 87.5-108 (Europe), 87.5-107.9 (America),65.0-108.0 (Russia) |
RDS | Yes |
iPod Control |
Touchscreen Control | Can Control Music Through Touchscreen |
Show Information Of Music | Yes |
Play Video | No |
Storage Media |
SD Card Slot For Music/Movie | micro SD card Slot |
MAX Memory Supported 16GB |
USB Port For Music/Movie | Mini USB Port |
MAX Memory Supported 16GB |
Position: USB port located in front panel and back of unit |
Portable HD | No |
Video & Audio |
Video Input | 1-Channel RCA Input |
Video Output | 2-Channel RCA Output |
Audio Input | 2-Channel RCA Input |
Audio Output | 4-Channel RCA Output |
Reverse Camera Input | Yes |
3 Zone Out | No |
Other Functions |
2-Zone | Yes (Listen Radio/CD While Watching GPS Image) |
3-Zone | No (Listening To Radio/Watching GPS Image At The Front And Watching DVD/SD/USB/TV From The Sub-monitor Simultaneously) |
Pictrue In Pictrue | No |
Steering Wheel Control Function | Yes |
CANBUS | No |
MFD | No |
TMC | No |
V-6 Disc Changer Memory | No |
CDC | No |
Parking Assistance | No |
Game | No |
Button Back Light | Red Illumination |
Accessories |
User Manual*1,Power Cable*1,Remote Control*1,iPod Control Wire*1, GPS Antenna*1,USB Cable*1 |
