| Prod Model: |
8D0047 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Display Type: |
Va Black Ground |
| Drive Method: |
1/4duty.1/3bias |
| Drive Voltager: |
5.0V |
| Polarizer Type: |
Transmissive |
| Operating Temp: |
-20-70 Degree |
| Storger Temp: |
-30-80degree |
| Connector: |
Pin Connector |
| Customerize: |
Yes |
| Cetification: |
RoHS |
| Type: |
TN |
| Application: |
Home Appliance, Autodvd, Meter |
| Aspect Ratio: |
Length*Width*Highth |
| Feature: |
Tn Va Silk Prin Screen Display |
| Screen Size: |
Length*Width*Highth |
| Interface Type: |
COB, Cog, Tab |
Product Description
Spec:
SIZE: Length*width*highth
DISPLAY TYPE: VA TN DISPLAY
LCD OPERATIONG VOLTAGE: 5.0v? (3V-5V. >2.8V IS OK)
OPERATING TEMP: -20-70C
STORGER TEMP: -30-80C
DRIVE MODE: 1/4DUTY, 1/3BIAS
VIEWING DIRECTION: 6H(BOTTOM VIEWING)---(12H, 6H, 3H, 9H)
POLARIZER TYPE: FRONT: TRANSMISSIVE,
BACK: TRANSMISSIVE
CONNECTOR: PIN (20)
BACKLIHGT: WHITE WITH TWO LIGHT, /BLUE BL (CUSTOMER DESIGN)
|
ITEMS |
TN- TYPE |
HTN-TYPE |
STN-TYPE |
FSTN-TYPE |
VA-TYPE |
|
Viewing Angle |
60º |
75º |
115º |
150º |
165º |
|
Contrast |
nomal |
nomal |
good |
high contrast |
high contrast |
|
Advantages |
1, easyly made
2, sales price
3, nomal materials
4, nomal product for black-white display |
1, viewing angle
wider than TN |
1, wide viewing angle
2, multi-display
3, wide range application
4, High -road driving |
1, nearly whole viewing angle
2, multi-display
3, wide-range application
4, High-road driving |
1, nearly whole viewing angle
2, multi-display
3, wide-range application
4, High-road driving
5, with color silk printing |
|
Disadvantages |
1, low viewing angle
2, sigle display model
3 lower driving method. |
Contrast nomally |
1, Complex manufacturing process
2, High cost.
|
1, Complex manufacturing process
2, High cost.
|
1, Complex manufacturing process
2, High cost.
|
|
Bitmap Bitmap Bitmap Bitmap
|
Caculator, Telephone,
nomall electronic products
|
Instruments and
Industrial meters |
Bitmap Bitmap
|
High-grade Instrument and meter |
|
High-grade Instrument
and meter |
Bitmap Bitmap
CarDVD, Home appliance,
Medical instrument |
|
|
Picture show |
|
|
|
Bitmap Bitmap |
|
|
|
|
|
|
|
|
|
|
|
