| Prod Model: |
L1-U |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
Lotussmart |
| Frequency: |
13.56MHz |
| Protocol: |
ISO 14443A |
| Smart Card Supported: |
Mifare_One S50 & S70 |
| Operating System: |
Win Nt Win 2000 Win XP Vista Win 7 Win 8 Android |
| Sdk Language: |
C Vb Vc Delphi Android |
| Installation: |
External |
| Card Slots: |
All in 1 & Multi in 1 |
| Interface: |
USB |
| Type: |
Memory Stick Card |
| Capacity: |
1m |
Product Description
Notes: You could download the SDK online, the link'd be offered after you purchase the RFID reader/writer. Contact me for Baidu SkyDrive download link.
Eatures
Typical time of command < 35 ms
Operating distance up to 10 cm
Bi-color LED (software control)
Buzzer alarm (software control)
Software Pack
SDK (C#, VB, VC, Delphi for demo program and source codes)
Demo program --- How to read and write data from the RFID card/tag
Source codes --- Speed up software development
Detailed DLL command set
Data sheet & User manual
USB to virtual COM driver: Specifications
Frequency : 13.56 MHz
Protocol : ISO14443 Type A
Card Support: For Mifare S50 & S70 / Ultralight / Ultralight C / for Mifare ProX
Operating Distance : Up to 10 cm (depends on the IC card / tag )
Read / Write Speed : 212 Kbps
Interface : USB (cable length: 1.5 meter)
Baud Rate : 115200 BPS
OS Support : Win NT, Win 2000, Win XP, Vista, Win 7, Win 8
Power : DC 5V (USB port)
Current : 42mA(operating); 22mA(close port); 60mA (Max. )
Indicator : LED + Buzzer (software controllable)
Operating Temperature : 10° C - 50° C
Storage Temperature : -20° C - 70° C
Relative Humidity : Up to 90%
Dimensions : 120 X 80 X 16 mm
Weight: 100 g (with cable)
Chongqing (Lotus) intelligent technology Co., Ltd. is a professional engaged in IC card read and write device (mainly for the contactless IC card read and write device, the RFID electronic tag, non-contact IC card reading and writing, speaking, reading and writing equipment, such as IC card read-write machine) with the technical research and development, sales and service promotion electronic company. The company has a group in the field of smart card has many years experience, good at studying, innovation of engineers and senior technicians, always adhere to the "high quality and low price, sincere service", take the customer as this, in a timely and flexible response to customer demand, providing customers with the best quality products, the most efficient, most intimate, the most economical personalized service, with our technical advantages, rich experience and high work enthusiasm will gradually introduce more updated products.
