| Prod Model: |
ATH-7 |
| Hi-Pot: |
DC 300V 10ms |
| Insulation Resistance: |
10m Ohm /300V Min |
| Contact Resistance: |
0.01 Ohm Max |
| Over Mold: |
PVC 80PA , Black or White |
| Application: |
Game Player |
| Color: |
Black |
| Type: |
Coaxial |
| Certification: |
VDE |
| Connector: |
RCA |
| Brand: |
Chaohon |
Product Description
Specifications
OFC Audio Cable
2*6.35mm to 2*rca cable
Mono jack plugs to phone plugs cable
Easy to use
OEM Products with low price
Specifications:
Usually used to connect from a left and right Mono 6.35mm output to an RCA Phono Auxiliary input. Backwardly compatible the cable also allows you to connect from an Auxiliary Output into left and right 6.35mm Mono inputs. Most commonly used with Mixers power amps and other audio equipment that require Mono interconnections.
This cable is constructed from an oxygen free copper ensuring the best possible sound. Colour coded ends make for easy identification.
Dual Mono Jack plugs 6.3mm
RCA Phono Jack plugs
Colour Coded ends
Oxygen free copper for the best possible sound
1.8m/6ft Cable (Fig 8 type)
Moulded ends for secure connection
Description:
-6.35mm mono audio cable
- Connectors: 6.35mm mono plug (male) to male
- Fully molding connectors provide excellent strain relief.
- High-quality coaxial wire with copper braid shield reduces unwanted noise and distortion.
- Gold-plated sterei connectors give you solid corrosion-free contact.
- Easy installation and convenient to carry
- Improves digital signal delivery as compared to standard stereo type audio cables.
- True digital signal maintained by high quality materials and connectors.
- 99.9% pure copper non-OFC conductor.
- High-density double shielding for maximum rejection of EMI and RFI.
Electrical:
1.100% open & short test;
2. Hi-Pot: DC 300V 10ms;
3. Insulation Resistance: 10M OHM /300V Min;
4. Contact Resistance: 0.01 OHM Max;
5. Shield upon 95% braid;
6. Working Temperature: -25oC ~ +85oC.
Mechanical:
Over mold: PVC 80Pa, ATH-7 Black or white;
Pre mold: PE Low Density;
Contact: Copper Alloy;
Insertion Force: 35 N Max;
Withdraw Force: 10 N Min.
|
Cable Type |
digital audio cable made in china |
|
Color available: |
white, black, red, green, blue, purple, pink, orange,yellow |
|
Cable length: |
1M /3FT |
|
Cable width: |
4mm |
|
Product weight: |
30g |
|
Packing type: |
Polybag or b ulk |
|
Compatible with: |
car,computer, mobile phone, TV set, DVD player, CD Player, headphone, speaker microphone, loudspeaker, MP3,MP4 and any other device which have 3.5mm audio port |
Xiamen Chaohong Electronic Technology Co., Ltd. Was founded in 2006. We specialized in the field of Wire Harness for 9 years. Our main product including: Homeappliance Wire Harness, Automobiles and Motorcycles Wire Harness, Equipment Wire Harness; UL Electronic Cables, Audio & Video Cables, MOLEX, JST and AMP connectors; Insulated and Uninsulated Terminal.
We manufacture as your requirements, also, we can source necessary products for you and sell directly to you.
We are committed to meeting environmental requirements. All of our products meet RoHS safety standards, also passed ISO9001 and 14001, UL and VDE certification.
We are confident to supply you with best product and service with reasonable price.
Our Advantage:
1. We are a professional manufacturer of wire harness for 9 years in China...
2. Our Wire Harness product have UL certificate: UL File No.: E477319
3. Strict Quality Control, 100% Test before delivery.
Our Service:
1. Your visit are highly welcome
2. Cutomize Order are welcome
3. OEM& ODM Service
4. Samples of our products will be provided for your evaluation.
Our factory Principle:
1. Environmental protection.
2. Defective rate are controlled below 1%
3. Speedy Delivery.
4. Guarantee: Replacement 1: 1 or refund for bad goods
5.100% satisfy your request as contract
What is out biggest wealth except customer? Neither the manager, nor the equipment, nor the building, but our worker. We insist on worker' s cultural construction, build fund to help the worker, Pre-job training.
