| Prod Model: |
990000335 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Mobile Phone |
| Type: |
TFT |
| 3D: |
Not 3D |
| Screen Size: |
3.5 |
Product Description
Panel Brand : TPO
Panel Model : TD035STEE1
Panel Type : LTPS TFT-LCD , Panel
Panel Size : 3.5 inch
Resolution : 480(RGB)×640 , VGA
Display Mode : TN, Normally White, Transflective
Active Area : 53.28×71.04 mm
Outline : 64×85 mm , Videowall Seam 0.0 mm
Surface :
Brightness : 150 cd/m² (Typ.)
Contrast Ratio : 200:1 (Typ.)(Transmissive) 8:1 (Typ.)(Reflective)
Display Colors : 262K (6-bit)
Response Time : 35 (Typ.)(Tr+Td)
Viewing Angle : 80/80/80/70 (Typ.)(CR≥5) (L/R/U/D)
Lamp Type : 6S1P WLED 8S6P: 8 Serial, 6 Parallel
Signal Interface : Parallel RGB (1 ch, 6-bit)
Input Voltage : 3.0/3.0V (Typ.)(VDDIO/VDC)
Toppoly LCD other item numbers for:
TD035STEB1: Acer3230/3250, N30/N35/N50
TD035STEB2: Dopod 699/696 (2ND gen)
TD035STEB3: HP1717/2110/2410/2750, HP ipaq hx21xx, ipaq 24xx/27xx
TD035STEB4: Acer N30/N35/N50, Asus A635
TD025THED1: Dopod C720, HTC S620
TD035STED1: Dopod D700 (1st gen, silver line)
TD028TTEB3: HTC TyTNII / HTC Kaiser / Dopod P4550
TD028TTEB2: Dopod C858
TD028TTEB1: Dopod P800
TD028TTEB2: Dopod C858
TD035STED3: Loox520, HP2470
TD035STED5: HP ipaq 194x/1950
TD028STEB1: Dopod 818/828/838
HongKong RMT Electronics Co., Ltd. is a professional manufacturer engaged in producing and developing switches, jacks and connectors. Meanwhile we meet customer`s requirement, supply world famous brand LCDs. We accept OEM and ODM order, welcome to visit our factory.
Quality is the core of enterprise development. RMT has been developing quickly and healthily these years based on strict quality management. We have strong technical force, advanced testing equipments, a group of specialized R&D engineers and skillful workers. We strictly carry out ISO9001 and formed our own quality system. We strictly carry out this standard in management, which enables us to earn a good reputation among our domestic and overseas customers.
We uphold the "high-quality products with the best price, win-win solution " of operating principles. RMT will provide you with best products and best service.
