| Prod Model: |
TM101JDHP01-00 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Operating Temperature: |
-20~70 |
| Storage Temperature: |
-30~80 |
| Viewing Direction: |
6:00 /12:00 |
| Backlight: |
LED(White) |
| Application: |
Instrument |
| Aspect Ratio: |
16:9 |
| Feature: |
LED Backlight Display |
| Type: |
TFT |
| Widescreen: |
Widescreen |
| Response Time: |
2ms |
| 3D: |
Not 3D |
| Screen Size: |
10.1 |
| Optimum Resolution: |
1280*800 |
| Interface Type: |
RGB(Ttl) |
Product Description
About shenzhen sheng he tai technology co. ltd,
we are the appointed agent of tianma and the global strategic partner. we can provide high quality tianma lcd module and excellent after-sales service.
Our advantages:
1.we are the authorized agents after review and filing by TIANMA, can provide certificate of authorization. For many years, we are responsible for the product's tender, distribution, promotion and sales as the value added partners(VAP) with TIANMA.
2.we are committed to the distribution of each piece of TIANMA LCD display is derived from the original factory and 100% new product.
3. When there is any problem in using the product, we can ask professional engineers from TIANMA to provide you with solutions until the problem is solved.
4. We can provide as the same quality standards as the original factory, and can get better after-sales service.
5.we have offices in Hongkong, Shenzhen and Shanghai, can provide more convenient services and faster logistics transportation.
| Feature | Spec |
| Display Spec. | Size | 10.1 inch |
| Display Spec. | Resolution | 1280(RGB)×800 |
| Display Spec. | Technology Type | a-si TFT |
| Display Spec. | Pixel Configuration | R.G.B. Vertical Stripe |
| Display Spec. | Pixel pitch(mm) | 0.1695x0.1695 |
| Display Spec. | Display Mode | TM, Normally Black |
| Display Spec. | Surface Treatment | HC |
Mechanical
Characteristics | LCM (W x H x D) (mm) | 229.46 x 149.10 x 2.50 |
Mechanical
Characteristics | Active Area(mm) | 216.96 x 135.60 |
Mechanical
Characteristics | With /Without TSP | Without TSP |
Mechanical
Characteristics | LED Numbers | 33 LED |
Mechanical
Characteristics | Weight (g) | TBD |
Electrical
Characteristics | Interface | LVDS 8-bit |
Electrical
Characteristics | Color Depth | 16.2M |
Electrical
Characteristics | Driver IC | ST5821CA*3 + ST5084CA*1 |
| Item | Symbol | Min | Max | Unit | Remark |
| Power Voltage | VDD | -0.3 | 3.9 | V |
|
| Power For Analog Circuit | AVDD | -0.3 | 14 | V |
|
| Gate On Voltage | VGH | -0.3 | 42 | V |
|
| Gate Off Voltage | VGL | -19 | 0.3 | V |
|
| Operating Temperature | TOPR | -10 | 50 | ºC |
|
| Storage Temperature | TSTG | -20 | 60 | ºC |
|
| Item | Symbol | Min | Typ | Max | Unit | Remark |
| POWER Supply Voltage | VDD | 2.80 | 3.30 | 3.60 | V |
|
| Power For Analog Circuit | AVDD | -- | 11 | -- | V |
|
| Gate On Voltage | VGH | -- | 23 | -- | V |
|
| Gate Off Voltage | VGL | -- | -7.0 | -- | V |
|
| Common Voltage | Vcom | -- | 4.3 | -- |
|
|
Input
Signal
Voltage | Low Level | VIL | GND | - | 0.2xVDD | V |
|
| High Level | VIH | 0.8xVDD | - | VDD | V |
Output
Signal
Voltage | Low Level | VIL | GND | - | 0.2xVDD | V |
|
| High Level | VIH | 0.8xVDD | - | VDD | V |
Page 7 of 19
| Parameter | Symbol | Value | Unit | Note |
| min | typ | max |
LVDS differential input high
threshold voltage | RxVTH | - | - | +100 | mV | RxVCM=1.2V |
LVDS differential input low
threshold voltage | RxVTL | -100 | - | - | mV |
LVDS differential input
common mode voltage | RxVCM | 0.7 | 1.2 | 1.6 | V |
|
| LVDS differential voltage | VID | 200 | - | 600 | mV |
|
