Switching Power Amplifier (FP-10000Q)
| Price: |
Negotiable |
| Trade Terms: |
FOB Guangzhou |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
FP-10000Q |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
FP series is a 4 channels switching power amplifier, with compact size, light weight, big power output and high stability, and same design inside as Labgruppen amplifier.
|
Model number |
FP-7000 |
FP-10000Q |
|
Output Power |
|
8Ω Stereo Power |
4 x 700 W |
4 x 1300 W |
|
4Ω Stereo Power |
4 x 1300 W |
4 x 2200 W |
|
2Ω Stereo Power |
4 x 1600 W |
4 x 2500 W |
|
8Ω Bridged Mono Power |
2 x 2650 W |
2 x 4400 W |
|
4Ω Bridged Mono Power |
2 x 3150 W |
2 x 5000 W |
|
/ |
|
Frequency Response |
20Hz-25KHz± 0.5dB |
|
THD+N(Pated power 8Ω /KHz)% |
0.1% |
|
Signal Noise Ration(dB) |
110dB |
|
Input Impedance |
20KΩ Balanced/> 10KΩ Unbalanced |
|
Panel |
|
Input Connectors |
Combo XLR type, 3pin |
|
Link Connectors |
XLR type, 3pin male |
|
Output Connectors |
Spoken x 4 (NEUTRIK) |
|
Power Supply |
AC 200V-240V/50Hz-60Hz |
|
LED Indicators |
|
LED Clip |
Orange |
Orange |
|
LED Signal |
Blue |
Blue |
|
LED Temp |
Yellow |
Yellow |
|
LED Active |
Blue |
Blue |
|
/ |
|
Dimensions (H*W*D) |
483x377x88mm |
483x377x88mm |
|
Weight (KG) |
15Kg |
15Kg |
Guangzhou Melody Industry Co., Limited is a professional manufacturer of PRO-audio products in Guangzhou, China. Specializes in research, developing, manufacturing, sales and technical services, With Excellent quality, Advanced technology, and Sincerely service.
Application scope: Our products are suitable for various of commercial activities, entertainment and recreation place. Such as Outdoor plaza, Stage performance, touring concert, Band, stadium, gymnasium, Church, theaters, Cinema, concert halls, auditorium, hotel, School, Disco bar, club, home party, Wedding, etc.
Main products: Passive/Active Line array speakers, PRO-Loudspeaker, monitors & Subwoofer, Karaoke system, etc. Analogue amplifiers, Switching power amplifiers, digital amplifier, Power Mixer, Digital signal processor, Accessories and so on.
Strong R&D: Our engineers and technicians have extensive experience and strong technical force, with the world advanced computer analysis system EASE4.0, electro-acoustic testing software DAAS3L, CAD assisted design software, carry out research on new materials, components and advanced product designs. Continuous researching and developing ensure that our products in high standard, and can meet with the most demanding needs of our customers.
