Prod Model: |
Sanway W8LC |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Type: |
12 Inch, Two Way |
Color: |
Black and Gray |
Amplification Type: |
Passive |
Usage: |
Karaoke |
Speaker Material: |
Wood |
SNR: |
70-80dB |
Structure: |
Bass Reflex Enclosure |
Sound Channel: |
2.0 |
Product Description
Single 12" Neodymium Line Array Cabinet Box W8LC Three Way Line Array Loudspeaker
1>. Line Array Speaker, Stage Line Array W8LC
2>. Mini Line Array System
3>. Audio Speaker Line Array
4>. Single 12" Neodymium Line Array
FEATURES
1). Compact, high performance three-way line array enclosure
2). High power - maximum SPL 129dB continuous, 135dB peak (single unit)
3). Superior bass impact - all horn design
4). Wide bandwidth - 60Hz-18kHz ± 3dB (single unit)
5). True 90° (-6dB) horizontal MID and HF pattern control
6). Very smooth off-axis response - useable out to 120° (-10dB)
7). Compatible with the full-sized W8L Line Array
8). Fast, integral rigging system with variable splay angles from 0° To 7.5°
9). Common grid may be used for flying or ground stacking
Specifications:
Line Array Component SpeakerW8LC |
Frequency Response (±3 dB) |
60 Hz - 18 kHz |
Sensitivity (1w/1m) |
LF 103 dB / MF 106 dB / HF 109 dB |
Maximum SPL |
LF 135 dB / MF 135 dB / HF 135 dB |
Nominal Impedance |
LF: 8 ohms MF: 8 ohms HF: 8 ohms |
Power rated(rms) |
LF: 400 watt MF: 200 watt HF: 100 watt |
Peak Power handling |
LF: 1600 watt MF: 800 watt HF: 400 watt |
Nominal Dispersion |
90ºH optional×7.5ºV |
Dimensions (H x W x D) |
367 mm x 1000 mm x 550 mm |
Enclosure Material |
18 mm plywood |
Surface Finished |
Textured grey wear-resistant paint |
Grille |
heavy grey perforated steel framed |
Net weight |
58kg |
Low Frequency Driver |
12" high effeciency Neodymium magnet driver |
Mid Frequency Driver |
2×6.5" high effeciency Neodymium magnet driver |
High Frequency Driver |
3×1" effeciency Neodymium magnet driver |
Input Connectors |
Speakon NL8×2 |
Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.
With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.
Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.
Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.
Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.
We always keep and follow the principle to do business:
The same product, we win by the quality;
The same quality, we win by the price,
The same price, we win by the service.
We sincerely hope that continuous business relationships can be established and please trust that we are always doing our best to realize good business relationships with our clients. We are constantly seeking new agents and distributors worldwide.
Don't hesitate to contact us if you are interested in any item, or should you have any special requirement, please kindly let us know directly, we will reply you as soon as possible.
